Key Specs
2342
sq ft
3
Beds
3.5
Baths
2
Floors
3
Garages
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 20-339
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 41'
Height : 32'
Width : 66'
Area
First Floor: 1189 sq/ft
Garage: 686 sq/ft
Second Floor: 1153 sq/ft
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Asphalt
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Bedroom Features
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Hobby Rec Room Game Room
Loft
Play Flex Room
Storage Area
Unfinished Future Space
Garage Features
Oversized Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Balcony
Covered Rear Porch
Rooms
Bathroom 2:
30 sq/ft width 5' 4" x depth 5' 8"
Bathroom 3:
55 sq/ft width 5' x depth 11'
Bathroom 4:
45 sq/ft width 6' 6" x depth 7'
Bedroom 2:
157 sq/ft width 14' 4" x depth 11'
Bedroom 3:
158 sq/ft width 11' 4" x depth 14'
Bonus Room - Unfinished:
400 sq/ft width 16' x depth 25'
Dining Room:
158 sq/ft width 11' 4" x depth 14'
Foyer:
48 sq/ft width 8' x depth 6'
Garage:
625 sq/ft width 29' 4" x depth 21' 4"
Kitchen:
197 sq/ft width 16' x depth 12' 4"
Kitchen Island:
27 sq/ft width 9' x depth 3'
Living Room:
373 sq/ft width 15' 4" x depth 24' 4"
Master Bathroom:
222 sq/ft width 12' x depth 18' 6"
Master Bedroom:
245 sq/ft width 15' 4" x depth 16'
Master Closet:
36 sq/ft width 9' x depth 4'
Pantry:
16 sq/ft width 4' x depth 4'
Utility Room:
44 sq/ft width 8' x depth 5' 6"
What's Included In This Plan Set
- Cover Page: Each home plan features the front elevation and informative reference sections including general notes and design criteria.
- Elevations: Drafted at ¼" scale for the front and 1/8" scale for the rear and sides. All elevations are detailed and an aerial view of the roof is provided, showing all hips, valleys, ridges and framing.
- Foundations: Drafted at ¼" - 1' scale. This plan is designed as a slab foundation. Optional basement or crawl space foundations are available. Basement foundations may require additional engineering for steel beam sizes.
- Main Level Floor Plan: Drafted at ¼" scale. 2" x 4" walls are standard. The detailed drawings include such things as ceiling treatments and header locations.
- Second Level Floor Plan: Drafted at ¼" scale. Drafted to the same degree of detail as the main level floor plan.
- Interior Elevations: Kitchen cabinet elevations are drawn.
- Electrical and Sections: The electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall, stair, brick sections are provided to further explain construction of these areas.
Plan Set
$949.50
$1215.00
Foundation
$0.00
$175.50
$175.50
Framing
$0.00
$175.50
Additional Options
$148.50
$35.10
$148.50
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
