PLAN 70-840
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 39'
Height : 28'
Width : 56' 4"
Area
First Floor: 1173 sq/ft
Garage: 655 sq/ft
Porch: 55 sq/ft
Second Floor: 1172 sq/ft
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Roof Type : Shingle
Secondary Pitch : 6:12
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : 2"x6"
Bedroom Features
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Additional Room Features
Den Office Study Computer
Great Room Living Room
Loft
Storage Area
Garage Features
Oversized Garage
Lot Characteristics
Suited For View Lot
Outdoor Spaces
Balcony
Covered Front Porch
Rooms
Basement Foundation:
2196 sq/ft width 56' 4" x depth 39'
Bathroom 2:
25 sq/ft width 5' x depth 5'
Bathroom 3:
55 sq/ft width 6' x depth 9' 2"
Bedroom 2:
121 sq/ft width 11' x depth 11'
Bedroom 2 Closet:
23 sq/ft width 5' x depth 4' 8"
Bedroom 3:
138 sq/ft width 11' 6" x depth 12'
Bedroom 3 Closet:
18 sq/ft width 2' x depth 9' 4"
Bedroom 4:
126 sq/ft width 11' x depth 11' 6"
Bedroom 4 Closet:
14 sq/ft width 2' x depth 7' 4"
Covered Porch:
50 sq/ft width 11' 8" x depth 4' 4"
Den:
132 sq/ft width 11' x depth 12'
Gathering Room:
285 sq/ft width 19' x depth 15'
Laundry Room:
30 sq/ft width 5' x depth 6'
Master Bathroom:
124 sq/ft width 11' x depth 11' 4"
Master Bedroom:
229 sq/ft width 13' x depth 17' 8"
Master Closet:
70 sq/ft width 11' x depth 6' 5"
