Key Specs
2879
sq ft
3
Beds
2.5
Baths
2
Floors
2
Garages
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 54-273
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 84' 6"
Height : 31' 10"
Width : 67' 4"
Area
Bonus: 166 sq/ft
First Floor: 2059 sq/ft
Garage: 585 sq/ft
Second Floor: 820 sq/ft
Roof
Primary Pitch : 0:0
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x4
Bedroom Features
Formal Dining Room
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Additional Room Features
Loft
Main Floor Laundry
Sunroom
Outdoor Spaces
Balcony
Covered Front Porch
Covered Rear Porch
Screened Porch
Rooms
Bedroom 2:
228 sq/ft width 14' 1" x depth 16' 3"
Bedroom 3:
131 sq/ft width 11' 1" x depth 11' 10"
Bedroom 4:
158 sq/ft width 11' 2" x depth 14' 2"
Breakfast:
166 sq/ft width 19' 2" x depth 8' 8"
Dining Room:
188 sq/ft width 14' 1" x depth 13' 5"
Garage:
457 sq/ft width 20' 5" x depth 22' 5"
Grand Room:
381 sq/ft width 18' 2" x depth 21'
Kitchen:
195 sq/ft width 13' 6" x depth 14' 6"
Loft:
114 sq/ft width 17' 4" x depth 6' 7"
Master Suite:
242 sq/ft width 15' 5" x depth 15' 9"
Sun Room:
203 sq/ft width 12' 5" x depth 16' 5"
