Key Specs


1791
sq ft

3
Beds

2
Baths

1
Floors

2
Garages

This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Floor Plans


Floor Plan - Main Floor Plan
Traditional Floor Plan - Main Floor Plan Plan #46-400

Full Specs & Features


Dimension Depth : 68' 1"
Height : 23'
Width : 51' 8"
Area Basement : 1791 sq/ft
Garage : 448 sq/ft
Main Floor : 1791 sq/ft
Porch : 91 sq/ft
Ceiling Main Ceiling : 8'
Roof Primary Pitch : 8:12
Exterior Wall Framing Framing : 2"x4"
Bedroom Features Walk In Closet
Kitchen Features Eating Bar
Walk In Pantry Cabinet Pantry
Additional Room Features Den Office Study Computer
Great Room Living Room
Storage Area
Lot Characteristics Suited For Sloping Lot
Outdoor Spaces Covered Front Porch
Covered Rear Porch
More Empty Nester
Bedroom 2 135 sq/ft width 11' 4" x depth 12'
Bedroom 2 Closet 11 sq/ft width 5' 7" x depth 2' 1"
Bedroom 3 116 sq/ft width 10' 2" x depth 11' 6"
Bedroom 3 Closet 13 sq/ft width 6' 6" x depth 2' 1"
Deck 144 sq/ft width 12' x depth 12'
Dining Room 137 sq/ft width 11' x depth 12' 6"
Foyer 88 sq/ft width 7' 11" x depth 11' 2"
Garage 471 sq/ft width 20' x depth 23' 7"
Gathering Room 342 sq/ft width 17' 6" x depth 19' 7"
Hall 33 sq/ft width 9' 6" x depth 3' 6"
Hall Bathroom 44 sq/ft width 8' 11" x depth 5'
Hall Closet 12 sq/ft width 6' x depth 2' 1"
Kitchen 154 sq/ft width 12' 2" x depth 12' 8"
Laundry Room 60 sq/ft width 10' x depth 6' 1"
Linen Closet 4 sq/ft width 2' 1" x depth 2' 1"
Master Bathroom 77 sq/ft width 6' x depth 12' 11"
Master Bedroom 197 sq/ft width 15' x depth 13' 2"
Master Closet 55 sq/ft width 11' 7" x depth 4' 9"
Pantry 16 sq/ft width 4' x depth 4'
Porch - Front 125 sq/ft width 17' 6" x depth 7' 2"
Porch - Rear 24 sq/ft width 6' 1" x depth 4'
Walk-In Closet width 0" x depth 0"

What's Included In This Plan Set


  • Elevations: Drawings of front, rear, right side and left side elevations drawn at 1/4" scale.
  • Foundation Plan: 1/4" scale foundation plan includes dimensions, actual steel beam and joist sizes. Most plans are designed for basement with a 7'10" pour and level lot (8" poured concrete wall).
  • Floor Plans: 1/4" scale plan that includes dimensions; actual header, flush beam, and joist sizes. Window rough opening sizes and locations. High quality windows and doors are specified on floor plan drawings. Location of bearing walls, direction of truss and rafter framing noted with size and spacing. Electrical layouts are shown.
  • Roof Plan: 1/8" scale plan indicates roof pitches, overhangs, saddles and chimneys
Miscellaneous Details:
  • Foundation reinforcing detail shows size of footing and foundation wall, size and spacing of rebar.
  • Beam and column detail shows connection of steel columns that are used to support steel beams at basement and footing detail to be installed below slab to support column load. Stair Detail to show builder how to frame with information such as tread and riser heights.
  • Cabinet layouts, included in drawings, can be used to show sizes of cabinets at kitchen to be installed. This detail can also be helpful should you want custom cabinets, it can be used by your cabinet people to show you what will fit in the space and your options available.
  • Truss profiles to show builder any irregular profiles, pitches, or heelcuts that varies from the typical framing.
  • Fireplace elevations that can be used as is to build your fireplace or to give you or your decorator a starting point.
  • Fireplace detail shows how the fireplace is to be built.
  • Wall section show typical framing detail of house.
» See important information before purchasing.
Plan Set
PDF Set :
$850.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
Reproducible Set :
$850.00
For making minor changes to your house plans and inexpensive local printing. 1 printed set on Vellum or Bond paper.
5 Copy Set :
$900.00
5 printed plan sets mailed to you.
8 Copy Set :
$950.00
8 printed plan sets mailed to you.
Foundation
Daylight Basement:
$0.00
Ideal for sloping lot, lower level of home partially underground.
Basement:
$350.00
Ideal for level lot, lower level of home partially or fully underground.
Crawlspace:
$350.00
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.
Slab:
$350.00
Ideal for level lot, single layer concrete poured directly on grade.
Additional Options
Material List :
75.00
A list of building supplies needed to construct the infrastructure of your new house.
Right-Reading Reverse :
115.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Construction Sets :
50.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Mirror Reversed Sets :
25.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Other Plans By this Designer
