PLAN 20-314
Key Specs
2888
sq ft
4
Beds
3.5
Baths
2
Floors
2
Garages
Cost to Build Reports Only $9.99 with Code CTB2022 (Limit 1)
This report will provide you cost estimates based on location and building materials.
Get Personalized Help
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 20-314
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Full Specs & Features
Height : 32'
Width : 54'
First Floor: 1817 sq/ft height 9'
Garage: 508 sq/ft
Second Floor: 1071 sq/ft
Roof Framing : Truss
Roof Type : Shingle
Framing : Wood - 2x4
Walk In Closet
Eating Bar
Great Room Living Room
Hobby Rec Room Game Room
Master Sitting Area
Suited For View Lot
Covered Rear Porch
Bathroom 2:
28 sq/ft width 5' x depth 5' 8"
Bathroom 3:
40 sq/ft width 8' x depth 5'
Bathroom 4:
61 sq/ft width 8' x depth 7' 8"
Bedroom 2:
122 sq/ft width 11' 8" x depth 10' 6"
Bedroom 3:
122 sq/ft width 11' 8" x depth 10' 6"
Bedroom 4:
169 sq/ft width 11' 8" x depth 14' 6"
Dining Room:
157 sq/ft width 11' 8" x depth 13' 6"
Foyer:
92 sq/ft width 8' x depth 11' 6"
Game Room:
304 sq/ft width 19' 8" x depth 15' 6"
Garage:
479 sq/ft width 21' 4" x depth 22' 6"
Kitchen:
164 sq/ft width 12' 8" x depth 13'
Living Room:
304 sq/ft width 19' 8" x depth 15' 6"
Master Bathroom:
150 sq/ft width 10' x depth 15'
Master Bedroom:
227 sq/ft width 14' 8" x depth 15' 6"
Master Closet:
68 sq/ft width 6' 4" x depth 10' 10"
Master Sitting Area:
24 sq/ft width 3' x depth 8'
Nook:
122 sq/ft width 9' 8" x depth 12' 8"
Study:
164 sq/ft width 11' 4" x depth 14' 6"
Utility Room:
56 sq/ft width 7' 4" x depth 7' 8"
What's Included In This Plan Set
- Cover Page: Each home plan features the front elevation and informative reference sections including general notes and design criteria.
- Elevations: Drafted at ¼" scale for the front and 1/8" scale for the rear and sides. All elevations are detailed and an aerial view of the roof is provided, showing all hips, valleys, ridges and framing.
- Foundations: Drafted at ¼" - 1' scale. This plan is designed as a slab foundation. Optional basement or crawl space foundations are available. Basement foundations may require additional engineering for steel beam sizes.
- Main Level Floor Plan: Drafted at ¼" scale. 2" x 4" walls are standard. The detailed drawings include such things as ceiling treatments and header locations.
- Second Level Floor Plan: Drafted at ¼" scale. Drafted to the same degree of detail as the main level floor plan.
- Interior Elevations: Kitchen cabinet elevations are drawn.
- Electrical and Sections: The electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall, stair, brick sections are provided to further explain construction of these areas.
| PDF Set : $922.25 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| CAD Set : $1173.00 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Foundation
| Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
| Basement: $165.75 |
Ideal for level lot, lower level of home partially or fully underground. |
| Crawlspace: $165.75 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
Framing
| Wood 2x4: $0.00 |
Wood 2x4 |
| Wood 2x6: $165.75 |
Wood 2x6 |
Additional Options
| Right-Reading Reverse : $165.75 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
| Audio Video Design : $85.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $33.15 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design : $85.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
