PLAN 20-1682
Key Specs
3408
sq ft
4
Beds
4
Baths
2
Floors
3
Garages
Cost to Build Reports Only $19.99 for a Limited Time!
This report will provide you cost estimates based on location and building materials.
Get Cost-To-Build Report
Or order by phone: 1-800-447-0027
Questions?
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-800-447-0027
Phone: 1-800-447-0027
Hours: Mon-Fri, 9AM - 8:30PM (EST)
See our Terms & Conditions and Privacy Policy.
PLAN 20-1682
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Full Specs & Features
Dimension
Depth : 63'
Height : 27'
Width : 95'
Height : 27'
Width : 95'
Area
Bonus: 560 sq/ft
First Floor: 3408 sq/ft height 9'
First Floor: 3408 sq/ft height 9'
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Main Ceiling : 9'
Roof
Primary Pitch : 8:12
Roof Framing : Conventional
Roof Type : Shingle
Secondary Pitch : 10:12
Roof Framing : Conventional
Roof Type : Shingle
Secondary Pitch : 10:12
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x4
Framing : Wood - 2x4
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Hobby Rec Room Game Room
Master Sitting Area
Mud Room
Play Flex Room
Storage Area
Sunroom
Hobby Rec Room Game Room
Master Sitting Area
Mud Room
Play Flex Room
Storage Area
Sunroom
Garage Features
Garage Under
Side Entry Garage
Side Entry Garage
Outdoor Spaces
Covered Front Porch
Screened Porch
Wrap Around Porch
Screened Porch
Wrap Around Porch
More
Jack & Jill Bath
Rooms
Bedroom 2:
171 sq/ft width 14' 4" x depth 12'
Bedroom 3:
171 sq/ft width 14' 4" x depth 12'
Bedroom 4:
193 sq/ft width 15' 6" x depth 12' 6"
Breakfast Room:
144 sq/ft width 12' x depth 12'
Dining Room:
203 sq/ft width 13' x depth 15' 8"
Garage:
667 sq/ft width 23' x depth 29'
Kitchen:
181 sq/ft width 14' 4" x depth 12' 8"
Living Room:
487 sq/ft width 24' x depth 20' 4"
Master Bedroom:
294 sq/ft width 14' x depth 21'
Porch - Screened:
288 sq/ft width 12' x depth 24'
Study:
217 sq/ft width 12' 4" x depth 17' 8"
What's Included In This Plan Set
- Cover Page: Each home plan features the front elevation and informative reference sections including general notes and design criteria.
- Elevations: Drafted at ¼" scale for the front and 1/8" scale for the rear and sides. All elevations are detailed and an aerial view of the roof is provided, showing all hips, valleys, ridges and framing.
- Foundations: Drafted at ¼" - 1' scale. This plan is designed as a slab foundation. Optional basement or crawl space foundations are available. Basement foundations may require additional engineering for steel beam sizes.
- Main Level Floor Plan: Drafted at ¼" scale. 2" x 4" walls are standard. The detailed drawings include such things as ceiling treatments and header locations.
- Second Level Floor Plan: Drafted at ¼" scale. Drafted to the same degree of detail as the main level floor plan.
- Interior Elevations: Kitchen cabinet elevations are drawn.
- Electrical and Sections: The electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall, stair, brick sections are provided to further explain construction of these areas.
