PLAN 952-254
Key Specs
11209
sq ft
5
Beds
5
Baths
2
Floors
4
Garages
Cost to Build Reports Only $9.99 with Code CTB2022 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 952-254
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.Plan Description
Full Specs & Features
Height : 35'
Width : 194' 8"
Second Floor: 2882 sq/ft height 9'
Roof Framing : Conventional
Framing : Wood - 2x4
Formal Dining Room
Formal Living Room / Parlor
Guest Suite
Split Bedrooms
Family Room Keeping Room
Great Room Living Room
Media Room
Covered Rear Porch
Bathroom 2:
120 sq/ft width 10' x depth 12'
Bathroom 4:
125 sq/ft width 10' x depth 12' 6"
Bathroom 5:
111 sq/ft width 11' 8" x depth 9' 7"
Bedroom 2:
175 sq/ft width 13' x depth 13' 6"
Bedroom 3:
387 sq/ft width 15' 6" x depth 25'
Bedroom 4:
375 sq/ft width 15' x depth 25'
Bedroom 5:
44 sq/ft width 5' 8" x depth 7' 10"
Breakfast Room:
149 sq/ft width 11' 6" x depth 13'
Den/Office or Bedroom 1:
451 sq/ft width 20' 6" x depth 22'
Dining Room:
384 sq/ft width 16' x depth 24'
Garage Storage:
93 sq/ft width 14' 4" x depth 6' 6"
Gathering Room:
575 sq/ft width 25' x depth 23'
Kitchen:
306 sq/ft width 18' x depth 17'
Living Room:
294 sq/ft width 15' 6" x depth 19'
Master Bedroom:
400 sq/ft width 17' 8" x depth 22' 8"
Master Closet:
154 sq/ft width 13' 4" x depth 11' 7"
Master Closet Two:
181 sq/ft width 10' 8" x depth 17'
Office:
255 sq/ft width 15' x depth 17'
Storage:
62 sq/ft width 6' 6" x depth 9' 8"
Utility Room:
164 sq/ft width 17' x depth 9' 8"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
| PDF Set : $4633.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
Foundation
| Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
Framing
| Wood 2x4: $0.00 |
Wood 2x4 |
Additional Options
| Additional Construction Sets : $60.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design : $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Mirror Reversed Sets : $55.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
