PLAN #513-2094

Key Specs


1277
sq ft

3
Beds

2
Baths

1
Floors

0
Garages

This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Floor Plans


Floor Plan - Main Floor Plan
Floor Plan - Main Floor Plan

Full Specs & Features


Dimension Depth : 53'
Height : 21'
Width : 31'
Area Garage : 480 sq/ft
Main Floor : 1277 sq/ft
Porch : 184 sq/ft
Ceiling Main Ceiling : 9'
Roof Primary Pitch : 8:12
Secondary Pitch : 8:12
Exterior Wall Framing Framing : 2x4
Bedroom Features Split Bedrooms
Walk In Closet
Kitchen Features Kitchen Island
Breakfast Nook
Peninsula Eating Bar
Additional Room Features Great Room Living Room
Main Floor Laundry
Storage Area
Garage Features Detached Garage
Lot Characteristics Suited For View Lot
Outdoor Spaces Covered Front Porch
Covered Rear Porch

What's Included In This Plan Set


WL Martin Home Designs

  • Cover Page: Each home plan features the front elevation and informative reference sections including general notes and design criteria.
  • Elevations: Drafted at ¼" scale for the front and 1/8" scale for the rear and sides. All elevations are detailed and an aerial view of the roof is provided, showing all hips, valleys, ridges and framing.
  • Foundations: Drafted at ¼" - 1' scale. This plan is designed as a slab foundation. Optional basement or crawl space foundations are available. Basement foundations may require additional engineering for steel beam sizes.
  • Main Level Floor Plan: Drafted at ¼" scale. 2" x 4" walls are standard. The detailed drawings include such things as ceiling treatments and header locations.
  • Second Level Floor Plan: Drafted at ¼" scale. Drafted to the same degree of detail as the main level floor plan.
  • Interior Elevations: Kitchen cabinet elevations are drawn.
  • Electrical and Sections: The electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall, stair, brick sections are provided to further explain construction of these areas.
» See important information before purchasing.
Plan Set
PDF Set :
$760.50
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
CAD Set :
$985.50
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Single Set :
$850.50
One printed set for bidding purposes only. Not a legal building set for construction.
Foundation
Slab:
$0.00
Ideal for level lot, single layer concrete poured directly on grade.
Basement:
$135.00
Ideal for level lot, lower level of home partially or fully underground.
Crawlspace:
$135.00
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.
Additional Options
Right-Reading Reverse :
135.00
Choose this option to reverse your plans and to have the text and dimensions readable.
