PLAN 23-637

Key Specs

1309
sq ft

3
Beds

1
Baths

1
Floors

0
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Floor Plans

Floor Plan - Main Floor Plan

Reverse

European Floor Plan - Main Floor Plan Plan #23-637

Full Specs & Features

Dimension

Depth : 36' 4"
Height : 27'
Width : 42'

Area

First Floor: 1309 sq/ft height 9'

*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 9'

Roof

Primary Pitch : 8:12
Roof Framing : Truss
Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Siding/Stone
Framing : Wood - 2x6

Kitchen Features

Eating Bar

Lot Characteristics

Suited For Narrow Lot

Outdoor Spaces

Covered Front Porch

Rooms

Bedroom 2:

110 sq/ft width 11' x depth 10'

Bedroom 2 Closet:

10 sq/ft width 5' 5" x depth 2'

Bedroom 3:

98 sq/ft width 10' x depth 9' 10"

Bedroom 3 Closet:

7 sq/ft width 3' 6" x depth 2'

Coat Closet:

12 sq/ft width 2' x depth 6' 2"

Family Room:

213 sq/ft width 13' 4" x depth 16'

Foyer:

32 sq/ft width 5' 4" x depth 6' 2"

Kitchen:

262 sq/ft width 17' 6" x depth 15'

Master Bathroom:

74 sq/ft width 10' 8" x depth 7'

Master Bedroom:

145 sq/ft width 12' 6" x depth 11' 8"

Master Closet:

22 sq/ft width 9' 2" x depth 2' 6"

Porch - Front:

207 sq/ft width 14' x depth 14' 10"

What's Included In This Plan Set
