PLAN 1070-57
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.Plan Description
The 193 sq. ft. listed for the basement is the stairway.
Full Specs & Features
Dimension
Depth : 38'
Height : 35' 7"
Width : 34'
Height : 35' 7"
Width : 34'
Area
Basement : 193 sq/ft
Garage : 907 sq/ft
Main Floor : 1073 sq/ft
Upper Floor : 351 sq/ft
Garage : 907 sq/ft
Main Floor : 1073 sq/ft
Upper Floor : 351 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Main Ceiling : 8'
Upper Ceiling Ft : 9'
Upper Ceiling Ft : 9'
Roof
Primary Pitch : 6/12
Roof Framing : Truss/Stick
Secondary Pitch : 12/12
Roof Framing : Truss/Stick
Secondary Pitch : 12/12
Exterior Wall Framing
Exterior Wall Finish : Stone/Siding
Framing : 2x6
Framing : 2x6
Bedroom Features
Split Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Upstairs Master Bedrooms
Walk In Closet
Additional Room Features
Great Room Living Room
Main Floor Laundry
Main Floor Laundry
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Narrow Lot
Outdoor Spaces
Covered Front Porch
More
Economical To Build
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
