PLAN 42-356
Key Specs
1434
sq ft
3
Beds
2
Baths
1
Floors
2
Garages
Cost to Build Reports Only $9.99 with Code CTB2021 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 42-356
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Full Specs & Features
Height : 23'
Width : 40'
Garage: 436 sq/ft
Roof Framing : Conventional
Roof Type : Shingle
Secondary Pitch : 10:12
Framing : 2"x4"
Main Floor Master Bedroom
Walk In Closet
Eating Bar
Storage Area
Suited For Narrow Lot
Covered Rear Porch
Bedroom 2:
128 sq/ft width 11' x depth 11' 8"
Bedroom 2 Closet:
10 sq/ft width 2' x depth 5' 2"
Bedroom 3:
143 sq/ft width 11' x depth 13'
Bedroom 3 Closet:
14 sq/ft width 2' x depth 7' 4"
Breakfast Room:
85 sq/ft width 8' 6" x depth 10'
Foyer:
65 sq/ft width 5' x depth 13'
Garage:
384 sq/ft width 18' 4" x depth 21'
Garage Storage:
23 sq/ft width 3' 4" x depth 7' 2"
Gathering Room:
277 sq/ft width 15' x depth 18' 6"
Hall:
56 sq/ft width 3' 8" x depth 15' 6"
Hall Bathroom:
40 sq/ft width 5' x depth 8'
Hall Closet:
6 sq/ft width 2' x depth 3'
Kitchen:
85 sq/ft width 8' 6" x depth 10'
Master Bathroom:
142 sq/ft width 10' 8" x depth 13' 4"
Master Bedroom:
197 sq/ft width 12' 4" x depth 16'
Master Closet:
80 sq/ft width 7' 6" x depth 10' 8"
Porch - Front:
105 sq/ft width 5' x depth 21'
Porch - Rear:
145 sq/ft width 8' x depth 18' 2"
Utility Room:
24 sq/ft width 3' x depth 8'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
| 5 Copy Set : $750.00 |
5 printed plan sets mailed to you. |
| 8 Copy Set : $800.00 |
8 printed plan sets mailed to you. |
| PDF Set : $800.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| Single Set : $700.00 |
One printed set for bidding purposes only. Not a legal building set for construction. |
Foundation
| Crawlspace: $0.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
| Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
Additional Options
| Right-Reading Reverse : $150.00 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
| Additional Construction Sets : $50.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design : $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design : $100.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
| Mirror Reversed Sets : $0.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
