Plan Description
This ranch design floor plan is 1465 sq ft and has 3 bedrooms and 2 bathrooms.
Floor Plans
Floor Plan - Main Floor
Full Specs & Features
Dimension
Depth : 45'
Height : 18'
Width : 58'
Area
Basement Unfinished: 1310 sq/ft
First Floor: 1465 sq/ft
Garage: 660 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Main Ceiling : 8'
Roof
Primary Pitch : 6:12
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : 2"x4"
Bedroom Features
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Additional Room Features
Family Room Keeping Room
Garage Features
Oversized Garage
Outdoor Spaces
Covered Front Porch
What's Included In This Plan Set
Plans are typically drawn to ¼” scale and include:
» See important
information before purchasing.
- Foundation Plan(s): 1/4" scale fully dimensioned foundation/basement plan. Also includes "future finish" recreation room, 1 or 2 bedrooms, bathroom and storage areas. Extra Items like fireplaces and wet bars are indicated as "optional".
- Floor Plan(s): Detailed plans for each level showing room dimensions, wall partitions, windows and doors, fixture locations, and ceiling treatments.
- Exterior Elevations: 1/4 inch scale elevations all the way around clarifies construction and helps with estimating materials and costs.
- Overhead Roof Plan(s): An eighth-inch scale "Birds-eye" view of the roof helps to simplify construction by showing all the valleys, hips, ridges etc.
- Cross Section(s): Complete front to back cross section with basic framing details. If included, the framing layout is intended to be a suggested layout only. Design loads and weather conditions vary by region. As a result the size, spacing, and layout of all structural elements in this home design may need approval by a structural engineer or code official based on your specific site location.
- Electrical Plan(s): Shown right on the floor plan, switches and outlets are located using standards of the National Electrical Code.
- Kitchen Cabinet Elevation(s): Detailed drawings of kitchen cabinet elevations. 1/2" scale.
- Construction Notes / Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
- Stair Detail(s): Drawings showing stair details. 1/2" scale. May also include fireplace details.
