Plan Description

The Azalea Trail provides a very functional split-floorplan layout with many of the features that your family desires. Expansive Master Bedroom and Bath with plenty of storage space in the separate walk-in closets. Large great room with vaulted ceiling and gas log fireplace. Front and rear porches. Open kitchen layout with plenty of counter space for that growing family. Great value with a wide variety of innovative features. Make this your home today!

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Full Specs & Features

Dimension

Depth : 47' 4"

Height : 22'

Width : 61'

Area

First Floor: 1500 sq/ft height 9'

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 9'

Roof

Primary Pitch : 8:12

Roof Framing : Conventional

Roof Type : Gable

Exterior Wall Framing

Exterior Wall Finish : Brick/Siding

Framing : 2 x 6

Bedroom Features

Split Bedrooms

Walk In Closet

Kitchen Features

Eating Bar

Additional Room Features

Great Room Living Room

Storage Area

Garage Features

Side Entry Garage

Lot Characteristics

Suited For Corner Lot

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

Rooms

Bathroom 2:

39 sq/ft width 7' x depth 5' 7"

Bedroom 2:

113 sq/ft width 11' x depth 10' 4"

Bedroom 2 Closet:

11 sq/ft width 5' x depth 2' 4"

Bedroom 3:

115 sq/ft width 11' 2" x depth 10' 4"

Bedroom 3 Closet:

12 sq/ft width 5' x depth 2' 7"

Coat Closet:

7 sq/ft width 3' 8" x depth 2'

Dining Room:

111 sq/ft width 10' 10" x depth 10' 4"

Garage:

499 sq/ft width 19' 4" x depth 25' 10"

Garage Storage:

17 sq/ft width 4' 8" x depth 3' 8"

Gathering Room:

296 sq/ft width 20' 8" x depth 14' 4"

Hall Closet:

4 sq/ft width 1' 8" x depth 2' 7"

Kitchen:

101 sq/ft width 9' 10" x depth 10' 4"

Laundry Room:

43 sq/ft width 7' 8" x depth 5' 8"

Linen Closet:

3 sq/ft width 1' 8" x depth 2' 4"

Master Bathroom:

127 sq/ft width 13' 8" x depth 9' 4"

Master Bedroom:

204 sq/ft width 13' 6" x depth 15' 2"

Master Closet - Hers:

39 sq/ft width 7' 2" x depth 5' 6"

Master Closet - His:

24 sq/ft width 6' 2" x depth 4'

Porch - Front:

8 sq/ft width 1' 8" x depth 5'

Porch - Rear:

102 sq/ft width 20' 6" x depth 5'

What's Included In This Plan Set

See a sample plan set

Plans are typically drawn to ¼” scale or larger and include:

Cover Sheet: Color rendering or black and white image of the exterior
Foundation Plan(s): Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Interior Elevations: Where applicable, each house plan set includes relevant interior elevations, including cabinets, cabinet details, columns and walls with unique conditions.
Overhead Roof Plan(s): Overhead view of roof.
Cross Section(s): A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Electrical Plan(s): Lighting, outlets, switches, detectors, etc.
Kitchen Cabinet Elevation(s): Scaled drawings of interior cabinets.
Construction Notes and Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
Framing Detail(s): Ceiling joist size and spacing and layouts. If included, the framing layout is intended to be a suggested layout only. Design loads and weather conditions vary by region. As a result the size, spacing, and layout of all structural elements in this home design may need approval by a structural engineer or code official based on your specific site location.
Wall Section(s): Exterior wall and roof sections and specialty details.
