PLAN 17-3360
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 80'
Height : 25' 4"
Width : 32'
Area
First Floor: 1534 sq/ft height 9'
Garage: 258 sq/ft height 9'
Porch: 272 sq/ft
Roof
Primary Pitch : 8:12
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Bedroom Features
Formal Dining Room
Walk In Closet
Kitchen Features
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Main Floor Laundry
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Rooms
Bedroom 2:
106 sq/ft width 10' x depth 10' 8"
Bedroom 3:
106 sq/ft width 10' x depth 10' 8"
Covered Porch:
158 sq/ft width 19' 10" x depth 8'
Dining Room:
118 sq/ft width 10' x depth 11' 10"
Foyer:
38 sq/ft width 5' 2" x depth 7' 6"
Garage:
240 sq/ft width 12' x depth 20'
Great Room:
285 sq/ft width 15' 6" x depth 18' 5"
Kitchen:
167 sq/ft width 15' 10" x depth 10' 7"
Master Suite:
189 sq/ft width 17' x depth 11' 2"
Porch - Rear:
66 sq/ft width 8' 4" x depth 8'
