PLAN 21-148
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 71'
Height : 22' 3"
Width : 50'
Area
First Floor: 1601 sq/ft
Ceiling
Main Ceiling : 9'
Roof
Primary Pitch : 10:12
Roof Framing : Combination Truss/Conventional
Roof Type : Hip / Gable
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : 2"x4"
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Kitchen Island
Additional Room Features
Great Room Living Room
Storage Area
Garage Features
Side Entry Garage
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Rooms
Bedroom 2:
135 sq/ft width 12' 4" x depth 11'
Bedroom 3:
135 sq/ft width 12' 4" x depth 11'
Eating:
118 sq/ft width 9' 4" x depth 12' 8"
Garage:
454 sq/ft width 20' 4" x depth 22' 4"
Great Room:
298 sq/ft width 16' x depth 18' 8"
Kitchen:
135 sq/ft width 10' 8" x depth 12' 8"
Master Bedroom:
190 sq/ft width 14' 6" x depth 13' 2"
Porch - Front:
80 sq/ft width 16' x depth 5'
Porch - Rear:
101 sq/ft width 16' x depth 6' 4"
