PLAN 57-692
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.Plan Description
This country style home has a second porch, which is private for the master bedroom. The great room has a fireplace, a vaulted ceiling, a vaulted atrium staircase with an arched window wall and convenient access to the rear patio and bedroom #3/study. A walk-in pantry, handy laundry room and breakfast area can be found near the well-planned kitchen with a center island. The master bedroom has a vaulted ceiling, arched windows with a planter box, two walk-in closets, a luxury bath with a separate shower and access to a porch. The lower level atrium has 89 square feet of living area which is included in the total square footage.
