PLAN 42-463
Key Specs
1679
sq ft
3
Beds
2
Baths
1
Floors
2
Garages
Cost to Build Reports Only $9.99 with Code CTB2021 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 42-463
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.Plan Description
Full Specs & Features
Height : 23'
Width : 60' 9"
Roof Framing : Conventional
Roof Type : Shingle
Framing : Wood - 2x4
Formal Dining Room
Main Floor Master Bedroom
Split Bedrooms
Kitchenette Wet Bar
Main Floor Laundry
Open Floor Plan
Covered Front Porch
Covered Rear Porch
3rd BR Closet:
16 sq/ft width 3' 4" x depth 5'
Bedroom 2:
135 sq/ft width 11' x depth 12' 4"
Bedroom 2 Closet:
14 sq/ft width 2' x depth 7'
Bedroom 3:
100 sq/ft width 10' x depth 10'
Bedroom 3 Closet:
14 sq/ft width 2' x depth 7'
Breakfast Room:
90 sq/ft width 9' x depth 10'
Dining Room:
135 sq/ft width 11' x depth 12' 4"
Foyer:
63 sq/ft width 7' x depth 9'
Garage:
400 sq/ft width 20' x depth 20'
Gathering Room:
287 sq/ft width 15' 8" x depth 18' 4"
Hall Bathroom:
50 sq/ft width 5' x depth 10'
Hall Closet:
6 sq/ft width 2' x depth 3' 4"
Kitchen:
120 sq/ft width 10' x depth 12'
Master Bathroom:
160 sq/ft width 10' x depth 16'
Master Bedroom:
195 sq/ft width 12' x depth 16' 4"
Master Closet:
25 sq/ft width 5' x depth 5'
Porch - Front:
168 sq/ft width 6' x depth 28'
Porch - Rear:
160 sq/ft width 10' x depth 16'
Utility Room:
48 sq/ft width 6' x depth 8'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
