PLAN 1100-10
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 74' 6"
Height : 15' 4"
Width : 50'
Area
Basement : 1720 sq/ft
Decks : 187 sq/ft
Garage : 670 sq/ft
Main Floor : 1720 sq/ft
Ceiling
Ceiling Details : The Foyer, Great Room, Rear Deck and Kitchen boasts 13-foot ceilings. The Dining and Master Suite have 10-foot ceilings with the Den/Bedroom having 11-foot ceilings.
Garage Ceiling : 10'
Lower Ceiling : 8'
Main Ceiling : 9'
Roof
Primary Pitch : 0
Roof Type : Flat
Secondary Pitch : 0
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Mud Room
Unfinished Future Space
Workshop
Garage Features
Oversized Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For Sloping Lot
Suited For View Lot
Outdoor Spaces
Grill Deck Sundeck
More
Economical To Build
Empty Nester
Suited For Vacation Home
Energy Efficient Features
Energy Efficient Design
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1631.00
$1881.00
$3156.00
Foundation
$0.00
$0.00
$200.00
$200.00
$200.00
Framing
$0.00
Additional Options
$200.00
$50.00
$165.00
$295.00
$39.00
$165.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
