PLAN 929-509

Photographs may show modified designs.

Save
  • Jump to:
  • All (6)
  • Floor plans (2)
Questions? Get Personalized Help

Key Specs


Plan Sq Ft

1891
sq ft

Plan Bedrooms

3
Beds

Plan Bathrooms

2.5
Baths

Plan Floors

2
Floors

Plan Garages

2
Garages

Select Plan Set Options

What's included?

Additional options

Dropdown arrow

Right-Reading Reverse
$235.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Audio Video Design
$100.00
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide
$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Material List
$325.00
A spreadsheet of building supplies needed to construct the infrastructure of your new house. Please note materials lists will not reflect add-ons such as alternate foundation and framing options.
Subtotal
$1475.00
Best Price Guaranteed*

Also order by phone: 1-800-447-0027

Questions about building your home?
Get Personalized Help
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-800-447-0027
Hours:
Ready for Your Call 7 Days a Week
Every Day 7 am - 8:30 pm Eastern

See our Terms & Conditions and Privacy Policy.


Wow!
Cost to Build Reports
are Only $4.99
with Code CTB2024 (limit 1)
This report will provide you cost estimates based on location and building materials.

Residential Construction Guide

Learn Building Basics

This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.

PLAN 929-509

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Plan Description


A striking central dormer window adds charm to the exterior of this plan while allowing natural light to flood the vaulted foyer. Sipping coffee and greeting neighbors each morning will become a family tradition, while the open living area with a generous great room with a fireplace and a practical U-shaped kitchen define comfortable living.

Full Specs & Features


Dimension

Depth : 39' 4"

Height : 27'

Width : 65' 8"

Area

Bonus: 572 sq/ft

First Floor: 1309 sq/ft height 9'

Second Floor: 582 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Ceiling Details : Two story cathedral ceiling in Foyer.

Main Ceiling : 9'

Upper Ceiling Ft : 8'

Roof

Primary Pitch : 12:12

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Siding

Framing : Wood - 2x4

Bedroom Features

Fireplace

Formal Dining Room

Garage Features

Side Entry Garage

Outdoor Spaces

Covered Front Porch

Deck

More

Economical To Build

Empty Nester

Rooms

3rd BR Closet:

20 sq/ft width 3' 4" x depth 6' 2"

Bathroom 2:

52 sq/ft width 9' 4" x depth 5' 8"

Bedroom 2:

162 sq/ft width 13' 4" x depth 12' 2"

Bedroom 2 Closet:

21 sq/ft width 6' 4" x depth 3' 4"

Bedroom 3:

162 sq/ft width 13' 4" x depth 12' 2"

Bedroom 3 Closet:

21 sq/ft width 6' 4" x depth 3' 4"

Bonus Room - Finished:

557 sq/ft width 28' 4" x depth 19' 8"

Breakfast Room:

117 sq/ft width 10' 8" x depth 11'

Deck:

245 sq/ft width 35' x depth 7'

Dining Room:

158 sq/ft width 11' 4" x depth 14'

Foyer:

42 sq/ft width 7' 4" x depth 5' 10"

Garage:

497 sq/ft width 21' x depth 23' 8"

Gathering Room:

244 sq/ft width 13' 4" x depth 18' 4"

Hall Closet:

6 sq/ft width 2' x depth 3' 4"

Kitchen:

144 sq/ft width 12' x depth 12'

Master Bathroom:

89 sq/ft width 7' x depth 12' 10"

Master Bedroom:

199 sq/ft width 13' 4" x depth 15'

Master Closet:

36 sq/ft width 6' x depth 6'

Porch - Front:

210 sq/ft width 35' x depth 6'

Powder Room:

30 sq/ft width 5' x depth 6'

Utility Room:

63 sq/ft width 7' x depth 9'

Walk-In Closet:

30 sq/ft width 3' 4" x depth 9' 2"
