PLAN 513-2051
Key Specs
1881
sq ft
3
Beds
2.5
Baths
2
Floors
3
Garages
Cost to Build Reports Only $19.99 for a Limited Time!
This report will provide you cost estimates based on location and building materials.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 513-2051
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Full Specs & Features
Height : 26'
Width : 59'
First Floor: 1454 sq/ft
Garage: 703 sq/ft
Second Floor: 437 sq/ft
Roof Framing : Roof Trusses
Roof Load : 30/20
Roof Type : Roof Trusses
Secondary Pitch : 8:12
Framing : 2"x4"
Upstairs Bedrooms
Kitchen Island
Great Room Living Room
Main Floor Laundry
Sunroom
Unfinished Future Space
Tandem Garage
Screened Porch
Bathroom 2:
18 sq/ft width 6' x depth 3'
Bathroom 3:
40 sq/ft width 8' x depth 5'
Bedroom 1:
184 sq/ft width 15' x depth 12' 4"
Bedroom 2:
132 sq/ft width 11' x depth 12'
Bedroom 3:
132 sq/ft width 11' x depth 12'
Bonus Room - Finished:
318 sq/ft width 24' 6" x depth 13'
Dining Room:
137 sq/ft width 11' x depth 12' 6"
Foyer:
53 sq/ft width 8' x depth 6' 8"
Garage:
418 sq/ft width 19' 4" x depth 21' 8"
Kitchen:
120 sq/ft width 10' x depth 12'
Kitchen Island:
39 sq/ft width 6' 6" x depth 6'
Living Room:
285 sq/ft width 15' x depth 19'
Master Bathroom:
83 sq/ft width 9' x depth 9' 4"
Master Closet:
55 sq/ft width 6' x depth 9' 4"
Nook:
100 sq/ft width 10' x depth 10'
Pantry:
3 sq/ft width 3' x depth 1'
Porch - Screened:
183 sq/ft width 15' 4" x depth 12'
Study:
137 sq/ft width 11' x depth 12' 6"
Utility Room:
46 sq/ft width 7' x depth 6' 8"
What's Included In This Plan Set
- Cover Page: Each home plan features the front elevation and informative reference sections including general notes and design criteria.
- Elevations: Drafted at ¼" scale for the front and 1/8" scale for the rear and sides. All elevations are detailed and an aerial view of the roof is provided, showing all hips, valleys, ridges and framing.
- Foundations: Drafted at ¼" - 1' scale. This plan is designed as a slab foundation. Optional basement or crawl space foundations are available. Basement foundations may require additional engineering for steel beam sizes.
- Main Level Floor Plan: Drafted at ¼" scale. 2" x 4" walls are standard. The detailed drawings include such things as ceiling treatments and header locations.
- Second Level Floor Plan: Drafted at ¼" scale. Drafted to the same degree of detail as the main level floor plan.
- Interior Elevations: Kitchen cabinet elevations are drawn.
- Electrical and Sections: The electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall, stair, brick sections are provided to further explain construction of these areas.
| PDF Set
: $1005.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| CAD Set
: $1300.00 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Foundation
| Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
| Basement: $195.00 |
Ideal for level lot, lower level of home partially or fully underground. |
| Crawlspace: $195.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
Framing
| Wood 2x4: $0.00 |
Wood 2x4 |
| Wood 2x6: $195.00 |
Wood 2x6 |
Additional Options
| Right-Reading Reverse
: $195.00 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
| Audio Video Design
: $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide
: $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design
: $100.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
