Plan Description


This ranch design floor plan is 1908 sq ft and has 1 bedrooms and 2.5 bathrooms.

Full Specs & Features


Dimension

Depth : 33'

Height : 26'

Width : 60'

Area

First Floor: 1908 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 8:12

Exterior Wall Framing

Exterior Wall Finish : Siding

Framing : Wood - 2x6

Bedroom Features

Formal Living Room / Parlor

Main Floor Master Bedroom

Kitchen Features

Kitchen Island

Additional Room Features

Den Office Study Computer

Rooms

Basement Foundation:

900 sq/ft width 40' 4" x depth 22' 4"

Dining Room:

158 sq/ft width 12' 6" x depth 12' 8"

Garage:

698 sq/ft width 24' 8" x depth 28' 4"

Living Room:

317 sq/ft width 18' 8" x depth 17'

Master Suite:

259 sq/ft width 17' 6" x depth 14' 10"

Office:

100 sq/ft width 10' x depth 10'

What's Included In This Plan Set


  • Exterior Elevations are scaled (1/4" and 1/8" = 1'-0") drawings of the front, rear, left, and right sides of the home.
  • Detailed Floor plans of the home accurately dimensioning the positioning of the walls, doors, windows, stairs, and permanent fixtures.
  • Foundation plan details the foot print of the home. Location and size of load points, stem walls, footings, pony walls, and floor joist.
  • Roof plans are typically truss planing, truss manufacturer will provide detail diagrams of truss's. In some cases the roof plans may be drawn as stick framed or have stick framing which will call out lumber sizes and spacing.
  • Cross Sections offer a cut away through the home showing your builder the correlation of building components.
  • Details indicate minimum CABO/IRC standards for construction of the home.
  • Electrical plan shows the schematic of the electrical layout. Most electricians want to discuss the options the home owner desires prior to bidding.
  • Mechanical and Detailed Plumbing plans are not included. These are site specific and are accomplished by those professionals.
  • All plans are prepared in compliance with the Uniform Building Code (ICBO) or the International Residential Code, a National Standard for residential construction at the time of completion.
