PLAN 929-687
Key Specs
1925
sq ft
3
Beds
2.5
Baths
1
Floors
2
Garages
Cost to Build Reports Only $19.99 for a Limited Time!
This report will provide you cost estimates based on location and building materials.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 929-687
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.Plan Description
Full Specs & Features
Height : 23'
Width : 70'
First Floor: 1925 sq/ft height 9'
Roof Framing : Conventional
Roof Type : Shingle
Framing : Wood - 2x4
Formal Dining Room
Split Bedrooms
Unfinished Future Space
Covered Rear Porch
3rd BR Closet:
12 sq/ft width 6' x depth 2'
Bathroom 2:
41 sq/ft width 8' 4" x depth 5'
Bedroom 2:
135 sq/ft width 12' x depth 11' 4"
Bedroom 2 Closet:
16 sq/ft width 2' x depth 8'
Bedroom 3:
135 sq/ft width 12' x depth 11' 4"
Bedroom 3 Closet:
16 sq/ft width 2' x depth 8'
Bonus Room - Finished:
279 sq/ft width 13' 4" x depth 21'
Breakfast Room:
73 sq/ft width 10' x depth 7' 4"
Dining Room:
162 sq/ft width 14' 4" x depth 11' 4"
Foyer:
71 sq/ft width 6' 4" x depth 11' 4"
Garage:
441 sq/ft width 21' x depth 21'
Garage Storage:
43 sq/ft width 13' 2" x depth 3' 4"
Gathering Room:
348 sq/ft width 18' 4" x depth 19'
Hall Closet:
6 sq/ft width 2' x depth 3'
Kitchen:
189 sq/ft width 12' 4" x depth 15' 4"
Master Bathroom:
105 sq/ft width 11' 4" x depth 9' 4"
Master Bedroom:
214 sq/ft width 14' x depth 15' 4"
Master Closet:
64 sq/ft width 11' 4" x depth 5' 8"
Porch - Front:
196 sq/ft width 32' 8" x depth 6'
Porch - Rear:
185 sq/ft width 25' 4" x depth 7' 4"
Powder Room:
34 sq/ft width 5' 8" x depth 6'
Utility Room:
52 sq/ft width 6' x depth 8' 8"
