PLAN 1064-27
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 69'
Height : 22' 10"
Width : 45'
Area
Basement : 1302 sq/ft
Decks : 139 sq/ft
Garage : 644 sq/ft
Main Floor : 1302 sq/ft
Patios : 186 sq/ft
Porch : 93 sq/ft
Upper Floor : 736 sq/ft
Ceiling
Garage Ceiling : 9' 3"
Lower Ceiling : 9'
Main Ceiling : 8' 1"
Upper Ceiling Ft : 8' 1"
Roof
Primary Pitch : 10/12
Roof Framing : Stick
Roof Load : 30 psf
Roof Type : Shingles
Secondary Pitch : 8/12
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : 2x6
Insulation : R-19
Bedroom Features
Main Floor Master Bedroom
Upstairs Bedrooms
Walk In Closet
Kitchen Features
Kitchen Island
Kitchenette Wet Bar
Additional Room Features
Great Room Living Room
Main Floor Laundry
Storage Area
Garage Features
Front Entry Garage
Side Entry Garage
Lot Characteristics
Suited For Narrow Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck
More
Additional Half Bath
Suited For Vacation Home
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1150.00
$1300.00
$1400.00
$2200.00
Foundation
$0.00
$295.00
$295.00
$395.00
$395.00
Framing
$0.00
$200.00
Additional Options
$245.00
$35.00
$165.00
$295.00
$39.00
$165.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
