PLAN 929-697
Key Specs
2073
sq ft
3
Beds
2.5
Baths
2
Floors
2
Garages
Now Just $17.99 for a Limited Time
This report will provide you cost estimates based on location and building materials.
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 929-697
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.Plan Description
Low-maintenance siding, a convenient front-entry garage, and architectural details such as gables and half circle transoms make this narrow-lot charmer perfect for beginning families and empty nesters. An abundance of windows and an open floor plan flood this home with natural light. Custom-styled features include a fireplace, two-story great room ceiling, kitchen pass-through, and French doors leading to the rear porch. The master suite is complete with a vaulted ceiling in the bedroom, walk-in and wardrobe closets, a double vanity, garden tub, and separate shower. Two secondary bedrooms share a full bath with the bonus room.
Full Specs & Features
Height : 26'
Width : 47'
First Floor: 1569 sq/ft
Second Floor: 504 sq/ft
Roof Framing : Conventional
Roof Type : Shingle
Framing : Wood - 2x4
Formal Dining Room
Unfinished Future Space
Covered Rear Porch
3rd BR Closet:
16 sq/ft width 8' x depth 2'
Bathroom 2:
70 sq/ft width 11' 10" x depth 6'
Bedroom 2:
132 sq/ft width 11' x depth 12'
Bedroom 2 Closet:
21 sq/ft width 3' 6" x depth 6'
Bedroom 3:
132 sq/ft width 11' 8" x depth 11' 4"
Bedroom 3 Closet:
21 sq/ft width 3' 6" x depth 6'
Bonus Room - Finished:
293 sq/ft width 13' 4" x depth 22'
Breakfast Room:
140 sq/ft width 12' x depth 11' 8"
Dining Room:
159 sq/ft width 11' 8" x depth 13' 8"
Foyer:
72 sq/ft width 7' 6" x depth 9' 8"
Garage:
484 sq/ft width 22' x depth 22'
Gathering Room:
302 sq/ft width 16' 10" x depth 18'
Hall Closet:
24 sq/ft width 7' 6" x depth 3' 4"
Kitchen:
128 sq/ft width 12' x depth 10' 8"
Master Bathroom:
92 sq/ft width 8' 2" x depth 11' 4"
Master Bedroom:
205 sq/ft width 14' 8" x depth 14'
Master Closet:
27 sq/ft width 4' 6" x depth 6'
Porch - Front:
108 sq/ft width 10' 4" x depth 10' 6"
Porch - Rear:
138 sq/ft width 17' 4" x depth 8'
Powder Room:
28 sq/ft width 5' x depth 5' 8"
Utility Room:
33 sq/ft width 5' 10" x depth 5' 8"
