This timeless country-style home is accented by a relaxing wraparound porch, perfect for sitting on a balmy summer night. Step into the foyer, which opens to the endearing family room, warmed by a corner fireplace. Through pocket doors, the dining room is ideal for family dinners. The nearby kitchen blends an island worktop, two pantries, and a desk to create an excellent place for meal preparation. Sunlight floods the breakfast nook, which offers access to the porch. The upper floor holds the master suite, which shows off another fireplace, a gigantic walk-in closet, and a private bath with a step-up tub and a flower box. Two secondary bedrooms, each with roomy closets, flank a full hall bath.
Full Specs & Features
Depth : 38'
Height : 31' 5"
Width : 56'
Bonus: 407 sq/ft
First Floor: 1136 sq/ft
Garage: 556 sq/ft
Second Floor: 993 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x6
Formal Dining Room
Upstairs Master Bedrooms
Walk In Closet
Additional Room Features
Family Room Keeping Room
What's Included In This Plan Set
Exterior Elevations (front, rear, left & right sides) typically include:
- Floor and ceiling heights
- Dimensions of standard windows
- Dimensions of roof overhangs
- Location of all needed flashings
- Height and location of foundation indicated in dashed lines
- Type of finishing and textures
- Dimension and height of chimney
Foundation plans typically include:
- All exterior and interior dimensions
- Thickness of foundation walls (if variable)
- All the structures needed to hold the first level, columns with load applications, beam sizes, variations in floor joists and their exact location
- Location of stairwell
- Location and sizes of windows
- Location and dimensions of footings (where applicable and required)
Floor plan(s) typically include:
- All interior and exterior dimensions
- Location and sizes of doors and windows
- Types of interior doors that correspond to a schedule
- Indication of the structure above (second floor or roof)
- Location of columns, beams and floor joists, including dimensions
- Indication of details that are available on other pages
Roof plans typically include:
- Location of all the different trusses needed
- The general overcharge of the roof compared to the floor footprint underneath
- Location of ridges and valleys
Building cross-section(s) and truss details typically include:
- All the different floor and ceiling heights
- Dimensions and design of trusses
- Dimensions and details of overhand
- Roof pitch on all truss sections
Construction details typically include:
- Roof sections
- Sections of concrete wall with wood connection
- Section of walls with particulars called out
- Section of concrete porch and connection with wood frame
- Foundation particulars in the garage entrance
- Components of certain types of walls (ex: between garage and living quarters)
Typical wall sections typically include;
» See important
information before purchasing.
- All the details and components needed in the construction of a house, including window section in a typical wall, connection between floor and exterior wall with their components, type of beam used.
- Note: This plan does not include an electrical layout.
