PLAN 51-1135
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 65' 5"
Height : 26' 9"
Width : 78' 11"
Area
Basement : 2150 sq/ft
Bonus : 535 sq/ft
Garage : 648 sq/ft
Main Floor : 2150 sq/ft
Ceiling
Bonus Ceiling : 8'
Garage Ceiling : 10' 6"
Lower Ceiling : 9'
Main Ceiling : 9'
Roof
Primary Pitch : 14:12
Roof Framing : trusses
Exterior Wall Framing
Exterior Wall Finish : siding
Framing : 2 x 6
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Butler's Pantry
Kitchen Island
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Master Sitting Area
Mud Room
Play Flex Room
Unfinished Future Space
Garage Features
Front Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
More
Jack & Jill Bath
What's Included In This Plan Set
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements. Drawn to 1/4" and 1/8" scale.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Roof Layout: Overhead view of roof showing ridges, valleys, and pitch.
- Note: These plans will not contain an electrical layout.
Plan Set
$1640.00
$1800.00
$1880.00
$1880.00
$2160.00
Foundation
$0.00
$320.00
$320.00
$320.00
$320.00
Framing
$0.00
$200.00
Additional Options
$200.00
$60.00
$132.00
$31.20
$132.00
$240.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
