Key Specs

sq ft





This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Plan Description

Designed for a corner lot, this looks more like a large home than a duplex. Unit A is a two-story, three bedroom, three-bath plan with a large great room 1343 sq ft - 694 1st flr - 649 2nd flr - 460 sq ft garage. Unit B is a single-level, two-bedroom plan with garages for three cars 998 sq ft - 950 sq ft garage

Floor Plans

Floor Plan - Upper Floor Plan
Contemporary Floor Plan - Upper Floor Plan Plan #124-804
Floor Plan - Main Floor Plan
Contemporary Floor Plan - Main Floor Plan Plan #124-804

Full Specs & Features

Depth : 81'
Height : 24' 6"
Width : 75'
First Floor: 694 sq/ft height 8'
First Floor: 998 sq/ft height 8'
Garage: 460 sq/ft height 8'
Garage: 950 sq/ft height 8'
Second Floor: 649 sq/ft height 8'
Main Ceiling : 8'
Roof Framing : 2x6
Roof Load : 25
Primary Pitch : 7:12
Roof Type : Truss
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : 2"x6"
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Upstairs Master Bedrooms
Kitchen Features
Eating Bar
Breakfast Nook
Additional Room Features
Great Room Living Room
Main Floor Laundry
Upstairs Laundry
Garage Features
Front Entry Garage
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Covered Front Porch
Grill Deck Sundeck
Code Compliance
Irc 2006
Structural Information Provided
Foundation Drawing
Structural 1st Floor Framing
Structural Roof Framing

Bedroom 2:

119 sq/ft width 11' x depth 10' 10"

Bedroom 2:

100 sq/ft width 10' x depth 10'

Bedroom 3:

96 sq/ft width 9' 10" x depth 9' 10"


439 sq/ft width 19' 8" x depth 22' 4"


381 sq/ft width 24' 4" x depth 15' 8"

Garage Two:

527 sq/ft width 24' 4" x depth 21' 8"

Great Room:

364 sq/ft width 15' x depth 24' 4"

Great Room:

403 sq/ft width 24' x depth 16' 10"

Master Suite:

127 sq/ft width 10' 6" x depth 12' 2"

Master Suite:

159 sq/ft width 12' x depth 13' 4"

What's Included In This Plan Set

Please note, if ordering a PDF set, it is not-modifiable. The CAD set is best for making local modifications

Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
  • Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
  • Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
  • Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
  • Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
  • Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details. Foundation types vary; please call to confirm the foundation type of the plan you are interested in.
  • Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
  • Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc. Specific details such as fireplaces, stairways, decks, etc. Details are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
  • Section: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation.
  • Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
