PLAN 137-169

Key Specs

2419
sq ft

4
Beds

3
Baths

2
Floors

2
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Floor Plans

Floor Plan - Main Floor Plan

Reverse

Southern Floor Plan - Main Floor Plan Plan #137-169

Floor Plan - Main Floor Plan

Reverse

Floor Plan - Upper Floor Plan

Reverse

Southern Floor Plan - Upper Floor Plan Plan #137-169

Floor Plan - Upper Floor Plan

Reverse

Full Specs & Features

Dimension

Depth : 74' 4"
Height : 29'
Width : 61' 8"

Area

Bonus: 367 sq/ft
First Floor: 1776 sq/ft height 9'
Second Floor: 643 sq/ft

*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 9'
Upper Ceiling Ft : 9'

Roof

Roof Framing : Conventional
Roof Type : Metal

Exterior Wall Framing

Exterior Wall Finish : Siding
Framing : Wood - 2x4

Bedroom Features

Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet

Kitchen Features

Breakfast Nook
Eating Bar

Additional Room Features

Great Room Living Room
Loft
Storage Area
Unfinished Future Space

Garage Features

Side Entry Garage

Lot Characteristics

Suited For Corner Lot

Outdoor Spaces

Balcony
Covered Front Porch
Covered Rear Porch

Rooms

Bedroom 2:

164 sq/ft width 13' x depth 12' 8"

Bedroom 3:

190 sq/ft width 13' x depth 14' 8"

Bedroom 4:

159 sq/ft width 12' x depth 13' 4"

Bonus Room - Finished:

330 sq/ft width 15' x depth 22'

Breakfast Room:

132 sq/ft width 12' x depth 11'

Dining Room:

177 sq/ft width 14' x depth 12' 8"

Foyer:

92 sq/ft width 7' 4" x depth 12' 8"

Garage:

498 sq/ft width 22' 8" x depth 22'

Gathering Room:

321 sq/ft width 15' 4" x depth 21'

Kitchen:

120 sq/ft width 10' x depth 12'

Laundry Room:

36 sq/ft width 6' x depth 6'

Master Bathroom:

127 sq/ft width 9' 4" x depth 13' 8"

Master Bedroom:

203 sq/ft width 13' x depth 15' 8"

Master Closet:

59 sq/ft width 9' 4" x depth 6' 4"

Porch - Front:

344 sq/ft width 38' 4" x depth 9'

Porch - Rear:

254 sq/ft width 28' 4" x depth 9'

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Designer’s rendering of front elevations
Foundation and dimensioned floor plans
Electrical plans
Section through house
All exterior elevation
Selected interior elevations; door and window sizes; fireplace details; stair details; molding details; cabinet details; roof plan and exterior details.
Roof Plan and Exterior Details

» See important information before purchasing.

Questions? Call 1-800-447-0027

Plan Set

5 Copy Set : $800.00	5 printed plan sets mailed to you.
8 Copy Set : $875.00	8 printed plan sets mailed to you.
PDF Set : $1100.00	PDF plan sets are best for fast electronic delivery and inexpensive local printing.
Reproducible Set : $1100.00	For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.
Single Set : $700.00	One printed set for bidding purposes only. Not a legal building set for construction.

Foundation

Basement: $0.00	Ideal for level lot, lower level of home partially or fully underground.
Crawlspace: $0.00	Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.

Additional Options

Additional Construction Sets : $55.00	Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design : $100.00	Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide : $39.00	Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design : $100.00	Receive an overlay sheet with suggested placement of lighting fixtures.
Mirror Reversed Sets : $55.00	A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.

*Alternate Foundations may take time to prepare.

*Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
