PLAN 137-204
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 81' 5"
Height : 29'
Width : 56' 11"
Area
Bonus: 401 sq/ft height 9'
First Floor: 1814 sq/ft height 9'
Second Floor: 627 sq/ft height 9'
Ceiling
Main Ceiling : 9'
Upper Ceiling Ft : 9'
Roof
Primary Pitch : 14:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x6
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Loft
Play Flex Room
Storage Area
Unfinished Future Space
Garage Features
Rear Entry Garage
Rear Garage
Outdoor Spaces
Balcony
Breezeway
More
Jack & Jill Bath
Rooms
Bedroom 2:
164 sq/ft width 12' x depth 13' 8"
Bedroom 3:
164 sq/ft width 12' x depth 13' 8"
Breakfast Room:
168 sq/ft width 14' x depth 12'
Dining Room:
180 sq/ft width 12' x depth 15'
Foyer:
124 sq/ft width 7' 4" x depth 17'
Garage:
506 sq/ft width 23' x depth 22'
Gathering Room:
402 sq/ft width 23' 8" x depth 17'
Kitchen:
182 sq/ft width 14' x depth 13'
Master Bedroom:
194 sq/ft width 12' x depth 16' 2"
Utility Room:
44 sq/ft width 7' x depth 6' 4"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
Plans are typically drawn to ¼” scale and include:
- Foundation Plan(s): This page shows all necessary notations and dimensions including footings, support columns, walls, and excavated/unexcavated areas.
- Floor Plan(s): Detailed plans for each level showing room dimensions, wall partitions, windows and doors, fixture locations, and ceiling treatments.
- Exterior Elevations: Views of the home from all four sides showing exterior materials, roof slope, ridge heights, siding and trim notes.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements.
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
- Building Section(s): Shows the relationship between different levels, wall heights, and the overall building volume. May include details like foundation, framing, insulation, and finishes.
- Electrical Plan(s): Shows the location of lights, receptacles, switches, etc. Some plans that do not include an electrical plan may have it available for an additional fee.
- Construction Notes / Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
- Rendering(s): Designer’s rendering of front elevation
Plan Set
$1230.00
$1365.00
$1050.00
Foundation
$0.00
Additional Options
$55.00
$165.00
$295.00
$39.00
$165.00
$55.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
