PLAN 124-577

Home > Style > Ranch House Plans

Key Specs

2958
sq ft

3
Beds

2.5
Baths

2
Floors

3
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Plan Description

This ranch design floor plan is 2958 sq ft and has 3 bedrooms and 2.5 bathrooms.

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Full Specs & Features

Dimension

Depth : 88' 11"

Height : 29'

Width : 83' 4"

Area

First Floor: 2473 sq/ft height 10'

Second Floor: 485 sq/ft height 10'

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 10'

Roof

Primary Pitch : 8:12

Roof Framing : Truss

Roof Load : 40

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : siding/brick

Framing : 2"x6"

Bedroom Features

Main Floor Bedrooms

Main Floor Master Bedroom

Split Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Eating Bar

Additional Room Features

Den Office Study Computer

Great Room Living Room

Loft

Main Floor Laundry

Master Sitting Area

Garage Features

Oversized Garage

Side Entry Garage

Lot Characteristics

Suited For View Lot

Outdoor Spaces

Balcony

Covered Front Porch

Covered Rear Porch

Wrap Around Porch

Empty Nester

Suited For Vacation Home

Unusual Shape

Rooms

Bathroom 2:

49 sq/ft width 9' 10" x depth 5'

Bedroom 2:

168 sq/ft width 13' 2" x depth 12' 10"

Bedroom 3:

227 sq/ft width 15' 2" x depth 15'

Garage:

804 sq/ft width 23' 4" x depth 34' 6"

Garage Two:

237 sq/ft width 19' x depth 12' 6"

Gathering Room:

673 sq/ft width 40' x depth 16' 10"

Home Office:

123 sq/ft width 8' 2" x depth 15' 2"

Kitchen:

240 sq/ft width 20' x depth 12'

Master Bathroom:

136 sq/ft width 10' 6" x depth 13'

Master Bedroom:

361 sq/ft width 19' x depth 19'

Utility Room:

56 sq/ft width 7' x depth 8'

What's Included In This Plan Set

See a sample plan set

Please note, if ordering a PDF Print Set, it is not-modifiable. The CAD set is best for making local modifications. The "5 set + PDF" combo contains a non-modifiable PDF Print Set.

Each plan set is drawn at 1/4"=1' scale and includes the following drawings:

Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details. Foundation types vary; please call to confirm the foundation type of the plan you are interested in.
Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc. Specific details such as fireplaces, stairways, decks, etc. Details are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
Section: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation.
Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.

Questions? Call 1-800-447-0027

Plan Set

PDF Print Set:
$1550.00

A non-modifiable, print only PDF file

5 Copy and PDF Set:
$1875.00

5 printed plan sets mailed to you plus PDF plan sets are best for fast electronic delivery and inexpensive local printing.

PDF Master Set:
$3175.00

An unlocked, modifiable PDF file

CAD Set:
$3550.00

For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Master Builder Package:
$3825.00

Includes CAD Set, PDF Masters and Unlimited Build License

Study Set:
$1250.00

One electronic set for bidding purposes only. Not a legal building set for construction.

Foundation

Slab:
$0.00

Ideal for level lot, single layer concrete poured directly on grade.

Crawlspace:
$475.00

Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.

Basement:
$600.00

Ideal for level lot, lower level of home partially or fully underground.

Daylight Basement:
$600.00

Ideal for sloping lot, lower level of home partially underground.

Framing

Wood 2x6:
$0.00

Wood 2x6 Exterior Walls

Wood 2x4:
$475.00

Wood 2x4 Exterior Walls

Additional Options

Right-Reading Reverse:
$410.00

Choose this option to reverse your plans and to have the text and dimensions readable.

Additional Construction Sets:
$65.00

Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Additional Use License:
$1250.00

Allows you to build one more home for each additional license purchased.

Audio Video Design:
$165.00

Receive an overlay sheet with suggested placement of audio and video components.

Comprehensive Material List:
$295.00

A complete list of building supplies needed to construct the infrastructure of your new house, plus an overlay of materials shown directly on your PDF (foundation to rooftop with interior and exterior materials), and a detailed, itemized door and window schedule showing all sizes and types. Please allow 5-7 Business Days for completion. Note, the Comprehensive list is only available with a PDF purchase. The Comprehensive list can be ordered no matter what additional plan options you have selected.

Construction Guide:
$39.00

Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design:
$165.00

Receive an overlay sheet with suggested placement of lighting fixtures.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
