3rd BR Closet:
28 sq/ft width 7' x depth 4'
50 sq/ft width 5' x depth 10'
45 sq/ft width 5' x depth 9'
165 sq/ft width 15' x depth 11'
Bedroom 2 Closet:
10 sq/ft width 5' x depth 2'
182 sq/ft width 13' x depth 14'
Bedroom 3 Closet:
10 sq/ft width 5' x depth 2'
168 sq/ft width 14' x depth 12'
Bedroom 4 Closet:
8 sq/ft width 4' x depth 2'
150 sq/ft width 15' x depth 10'
222 sq/ft width 16' 6" x depth 13' 6"
72 sq/ft width 6' x depth 12'
528 sq/ft width 24' x depth 22'
352 sq/ft width 16' x depth 22'
162 sq/ft width 18' x depth 9'
135 sq/ft width 9' x depth 15'
240 sq/ft width 16' x depth 15'
77 sq/ft width 11' x depth 7'
Porch - Front:
42 sq/ft width 6' x depth 7'
Porch - Rear:
216 sq/ft width 18' x depth 12'
66 sq/ft width 11' x depth 6'
72 sq/ft width 9' x depth 8'
All plans are drawn at ¼” scale or larger and include :
|5 Copy Set :
|5 printed plan sets mailed to you.|
|8 Copy Set :
|8 printed plan sets mailed to you.|
|Reproducible Set :
|For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.|
|Single Set :
|One printed set for bidding purposes only. Not a legal building set for construction.|
|Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.|
|Ideal for level lot, single layer concrete poured directly on grade.|
|Additional Construction Sets :
|Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).|
|Audio Video Design :
|Receive an overlay sheet with suggested placement of audio and video components.|
|Construction Guide :
|Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.|
|Lighting Design :
|Receive an overlay sheet with suggested placement of lighting fixtures.|
|Material List :
|A list of building supplies needed to construct the infrastructure of your new house for the standard plan. Please note materials list will not reflect optional add-ons such as foundation and framing.|
|Mirror Reversed Sets :
|A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.|
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
