Plan Description


This plan fulfills the contemporary demand for an open-concept floor plan while retaining the character and charm of traditional Craftsman styling. Eave brackets and graceful tapered columns contribute major curb appeal. Inside, the great room flows into the open dining area and then the kitchen, where an island offers plenty of prep space and a snack bar. The den/nursery connects to the master suite to give you tremendous flexibility: use it now to keep a close eye on your baby, then convert it to an office later. Three more bedrooms rest upstairs, including one with a private bathroom.

Full Specs & Features


Dimension

Depth : 54' 6"

Height : 26' 8"

Width : 72' 10"

Area

Basement Unfinished: 1551 sq/ft

First Floor: 1544 sq/ft height 10'

Garage: 705 sq/ft

Second Floor: 942 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 8:12

Roof Framing : Conventional

Roof Type : Asphalt

Secondary Pitch : 4:12

Exterior Wall Framing

Exterior Wall Finish : Brick/Stone

Framing : Wood - 2x6

Bedroom Features

Fireplace

Main Floor Master Bedroom

Split Bedrooms

Walk In Closet

Kitchen Features

Kitchen Island

Kitchenette Wet Bar

Additional Room Features

Den Office Study Computer

Great Room Living Room

Loft

Main Floor Laundry

Open Floor Plan

Garage Features

Front Entry Garage

Golf Cart Storage

Rear Entry Garage

Outdoor Spaces

Balcony

Courtyard

Covered Front Porch

Outdoor Fireplace

Rooms

Bedroom 2:

144 sq/ft width 12' x depth 12'

Bedroom 3:

132 sq/ft width 11' x depth 12'

Bedroom 4:

126 sq/ft width 14' x depth 9'

Covered Front Porch:

276 sq/ft

Den/ Nursery:

140 sq/ft width 10' x depth 14'

Garage:

705 sq/ft

Great Room:

480 sq/ft width 20' x depth 24'

Kitchen:

304 sq/ft width 16' x depth 19'

Master Bedroom:

224 sq/ft width 16' x depth 14'

Rear Patio:

121 sq/ft

What's Included In This Plan Set


All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
