PLAN 1080-13

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Plan Description


Open floor plan with 1st floor living with an office. On 2st floor there are additional bedrooms a loft and unfinished space.

Full Specs & Features


Dimension

Depth : 44' 3"

Height : 32'

Width : 51' 2"

Area

Decks : 63 sq/ft

Main Floor : 1774 sq/ft

Porch : 272 sq/ft

Storage : 198 sq/ft

Upper Floor : 722 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 10'

Upper Ceiling Ft : 9'

Roof

Primary Pitch : 10/12

Roof Type : Engineered

Secondary Pitch : 14/12

Exterior Wall Framing

Framing : 2x4

Bedroom Features

Main Floor Master Bedroom

Upstairs Bedrooms

Walk In Closet

Kitchen Features

Kitchen Island

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Family Room Keeping Room

Loft

Main Floor Laundry

Mud Room

Storage Area

Unfinished Future Space

Outdoor Spaces

Covered Front Porch

Screened Porch

More

Suited For Vacation Home

What's Included In This Plan Set


All plans are drawn at ¼” scale or larger and include:

  • Cover Sheet, Index of Sheets and Floor and Wall Framing notes and square footage for this house.
  • Exterior Elevations: a blueprint picture of all 4 sides drawn in ¼” scale, showing exterior materials and floor measurements. There may be additional illustrations with measurements of special features.
  • Foundation Page: Drawn to ¼” scale, this page shows all necessary notations and dimensions including footing locations, pads, and support walls with excavated and unexcavated areas.
  • Floor Plan(s): Detailed plans drawn to ¼” scale for each level showing room dimensions, window and door sizes, bearing walls and beam locations and bearing points.
  • Roof layout: Detailing what is Engineered Trussed, stick built and any build overs. There may be additional illustrations with measurements of special features.
  • Cross sections: Illustrates a vertical cutaway view of the house from roof down to foundation. These wall sections specify construction and building materials. The number of stories, floor heights, framing details, and the flow of bearing points down to the foundation.
  • Trim detail: Illustrates where crown moulding and wainscotting are located in the house. Additional illustrations of special features may be included. Cabinet designs are not included, since most people visit with a cabinet supplier for their unique needs. Room sizes can be referenced back on the Floor Plan for the opening sizes.
  • Electrical Layout: Is an illustration of where light switches and outlets are located, for a homeowner perspective. The illustration does not conform to the Electrical Standard symbols on the plan, but is a more simplified version for a homeowner understanding.
  • » See important information before purchasing.
    Questions? Call 1-800-447-0027

    Plan Set

    PDF Set:
    $1147.50
    PDF plan sets are best for fast electronic delivery and inexpensive local printing.
    CAD Single Build:
    $1695.75
    For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
    CAD Unlimited Build:
    $2205.75
    For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

    Foundation

    Crawlspace:
    $0.00
    Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.

    Framing

    Wood 2x4:
    $0.00
    Wood 2x4 Exterior Walls

    Additional Options

    Audio Video Design:
    $85.00
    Receive an overlay sheet with suggested placement of audio and video components.
    Construction Guide:
    $33.15
    Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
    Mirror Reversed Sets:
    $191.25
    A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.

    *Alternate Foundations may take time to prepare.

    *Options with a fee may take time to prepare. Please call to confirm.

    Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
