PLAN 21-416
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 53' 6"
Height : 26' 4"
Width : 79' 4"
Area
Basement Unfinished: 2100 sq/ft
First Floor: 2100 sq/ft
Garage: 569 sq/ft
Second Floor: 405 sq/ft
Storage: 249 sq/ft
Roof
Primary Pitch : 10:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x4
Additional Room Features
Den Office Study Computer
Great Room Living Room
Open Floor Plan
Vaulted / Cathedral Ceilings
Workshop
Rooms
Bedroom 2:
144 sq/ft width 12' x depth 12'
Bedroom 3:
132 sq/ft width 12' x depth 11'
Breakfast Area:
108 sq/ft width 12' x depth 9'
Covered Porch:
119 sq/ft width 17' x depth 7'
Dining Room:
156 sq/ft width 12' x depth 13'
Flex Room:
435 sq/ft width 13' x depth 33' 6"
Foyer:
98 sq/ft width 14' x depth 7'
Garage:
576 sq/ft width 24' x depth 24'
Great Room:
391 sq/ft width 17' x depth 23'
Kitchen:
180 sq/ft width 12' x depth 15'
Laundry Room:
44 sq/ft width 4' x depth 11'
Master Bedroom:
252 sq/ft width 14' x depth 18'
Master Closet - Hers:
54 sq/ft width 6' x depth 9'
Master Closet - His:
48 sq/ft width 6' x depth 8'
Office:
143 sq/ft width 11' x depth 13'
Porch - Front:
246 sq/ft width 41' x depth 6'
Porch - Screened:
147 sq/ft width 21' x depth 7'
What's Included In This Plan Set
- Cover Sheet: Showing architectural rendering of residence
- Floor Plan(s): In general, each house plan set includes floor plans at 1/4" scale with a door and window schedule. Floor plans are typically drawn with 4" exterior walls. However, some plans may have details/sections for both 2"x4" and 2"x6" wall framing. Please see "Exterior Wall Framing" specification above for availability.
- Foundation Plan and Details
- Electrical Plan with electrical symbols legend: In general, each house plan set includes an electrical plan which will show the locations of lights, receptacles, switches, etc.
- Roof Drainage Plan: In general each house plan set may include a roof drainage plan which will show the layouts of all roof sections/planes.
- Exterior Elevations: In general, each house plan set includes all applicable front, sides and rear elevations, as well as any special exterior details.
- Interior Elevations: Where applicable, each house plan set includes relevant interior elevations, including cabinets, cabinet details, columns and walls with unique conditions.
Plan Set
$1256.00
$1344.00
$1432.00
$1588.00
$1860.00
Foundation
$0.00
$0.00
Framing
$0.00
Additional Options
$120.00
$48.00
$120.00
$31.20
$120.00
$40.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
