PLAN 929-45

Photographs may show modified designs.

Save
  • Jump to:
  • All (6)
  • Floor plans (2)
Questions? Get Personalized Help

Key Specs


Plan Sq Ft

2506
sq ft

Plan Bedrooms

4
Beds

Plan Bathrooms

3.5
Baths

Plan Floors

2
Floors

Plan Garages

2
Garages

Select Plan Set Options

What's included?

Additional options

Dropdown arrow

Right-Reading Reverse
$250.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Audio Video Design
$100.00
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide
$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Material List
$325.00
A spreadsheet of building supplies needed to construct the infrastructure of your new house. Please note materials lists will not reflect add-ons such as alternate foundation and framing options.
Subtotal
$1675.00
Best Price Guaranteed*

Also order by phone: 1-800-447-0027

Questions about building your home?
Get Personalized Help
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-800-447-0027
Hours:
Ready for Your Call 7 Days a Week
Every Day 7 am - 8:30 pm Eastern

See our Terms & Conditions and Privacy Policy.


Wow!
Cost to Build Reports
are Only $4.99
with Code CTB2024 (limit 1)
This report will provide you cost estimates based on location and building materials.

Residential Construction Guide

Learn Building Basics

This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.

PLAN 929-45

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Modify This Plan

Plan Description


This traditional design floor plan is 2506 sq ft and has 4 bedrooms and 3.5 bathrooms.

Full Specs & Features


Dimension

Depth : 58' 11"

Height : 35'

Width : 48'

Area

Bonus: 293 sq/ft height 9'

First Floor: 1615 sq/ft height 9'

Garage: 579 sq/ft height 9'

Porch: 292 sq/ft

Second Floor: 891 sq/ft height 9'

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Bonus Ceiling : 9'

Ceiling Details : Two-story ceiling in Great Room; step ceiling in master Bedroom, cathedral ceilings in 2 upper level bedrooms

Main Ceiling : 9'

Upper Ceiling Ft : 9'

Roof

Primary Pitch : 11/12

Roof Framing : Conventional

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Brick/Siding

Framing : 2 x 4

Bedroom Features

Main Floor Master Bedroom

Split Bedrooms

Upstairs Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Kitchen Island

Walk In Pantry Cabinet Pantry

Additional Room Features

Great Room Living Room

Main Floor Laundry

Play Flex Room

Unfinished Future Space

Garage Features

Front Entry Garage

Outdoor Spaces

Covered Front Porch

Rooms

Bedroom 2:

141 sq/ft width 11' 4" x depth 12' 6"

Bedroom 3:

137 sq/ft width 11' x depth 12' 6"

Bedroom 4:

148 sq/ft width 11' 5" x depth 13'

Bonus Room - Finished:

270 sq/ft width 11' 5" x depth 23' 8"

Breakfast:

113 sq/ft width 11' 4" x depth 10'

Dining Room:

143 sq/ft width 11' x depth 13'

Foyer:

49 sq/ft width 5' x depth 9' 10"

Garage:

529 sq/ft width 22' 1" x depth 24'

Great Room:

300 sq/ft width 17' 8" x depth 17'

Kitchen:

135 sq/ft width 11' 4" x depth 12'

Master Bedroom:

201 sq/ft width 14' 5" x depth 14'

Utility Room:

58 sq/ft width 5' 8" x depth 10' 4"
