PLAN 1067-5
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 83' 8"
Height : 0"
Width : 42' 6"
Area
Garage : 516 sq/ft
Main Floor : 1948 sq/ft
Porch : 525 sq/ft
Storage : 38 sq/ft
Upper Floor : 562 sq/ft
Ceiling
Main Ceiling : 10'
Upper Ceiling Ft : 9'
Roof
Primary Pitch : 10/12
Roof Framing : Stick
Roof Type : Shingles/Metal
Secondary Pitch : 3/12
Exterior Wall Framing
Exterior Wall Finish : Siding/Brick
Framing : 2x4
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Upstairs Bedrooms
Walk In Closet
Kitchen Features
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Main Floor Laundry
Storage Area
Garage Features
Rear Entry Garage
Lot Characteristics
Suited For Narrow Lot
Outdoor Spaces
Covered Front Porch
Screened Porch
What's Included In This Plan Set
- Cover Sheet: May include index, front view of home, definitions, etc.
- Foundation Plan(s): Typically includes dimensioned foundation plan with footing details.
- Floor Plan(s): Electrical may be shown.
- Exterior Elevations: Four exterior views of the residence with other miscellaneous details.
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
- Building Section(s): Section through home displaying necessary information about framing and other miscellaneous data.
- Electrical Plan(s): Displays all switches, lighting fixtures, outlets and other necessary electrical items. These items may be shown on the Floor Plan.
- Kitchen Cabinet Elevation(s): Displays interior kitchen cabinet views.
- Construction Notes and Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
- Wall Section(s): Detail of wall materials and assembly.
Plan Set
$1595.00
$1845.00
$2295.00
$2545.00
$2695.00
Foundation
$0.00
$100.00
$395.00
Framing
$0.00
$325.00
Additional Options
$225.00
$100.00
$495.00
$165.00
$39.00
$165.00
$250.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
