PLAN 1098-15
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 63' 1"
Height : 28'
Width : 49' 5"
Area
Garage : 744 sq/ft
Main Floor : 1807 sq/ft
Patios : 261 sq/ft
Porch : 143 sq/ft
Upper Floor : 720 sq/ft
Ceiling
Ceiling Details : DINING/LIVNG RM; VAULTED
Main Ceiling : 10'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 12:12
Roof Framing : STICK/TRUSS
Secondary Pitch : 9:12
Exterior Wall Framing
Exterior Wall Finish : BOARD & BATTEN, BRICK
Framing : STICK/TRUSS
Bedroom Features
Guest Suite
Main Floor Bedrooms
Main Floor Master Bedroom
Upstairs Bedrooms
Walk In Closet
Kitchen Features
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Exercise Room
Hobby Rec Room Game Room
Main Floor Laundry
Media Room
Mud Room
Play Flex Room
Storage Area
Garage Features
Front Entry Garage
Lot Characteristics
Suited For Narrow Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
More
Economical To Build
What's Included In This Plan Set
- Foundation Plan(s): Includes dimensioned foundation plan with footing details.
- Floor Plan(s): Shows a window and door schedule and placements, dimensions of interior and exterior spaces.
- Exterior Elevations: Four exterior views of the residence with other miscellaneous details and/or renderings of the house.
- Overhead Roof Plan(s): Birds eye view showing ridges, valleys and roof pitch.
- Cross Section(s): Section through home displaying necessary information about framing and other miscellaneous data.
- Electrical Plan(s): Displays all lighting fixtures, outlets and other necessary electrical items.
- Construction Notes / Detail(s): Special notes pertaining to the build of the residence, assembly information, any specific code notes.
- Wall Section(s): Shows the elements needed to construct the walls, and an interior finish schedule.
- Door / Window Schedule(s): A list of all the doors and windows needed to construct the house. This can help with estimating materials costs.
Plan Set
$1185.75
$1398.25
$1695.75
$2035.75
Foundation
$0.00
$255.00
Framing
$0.00
$250.75
Additional Options
$191.25
$297.50
$140.25
$250.75
$33.15
$140.25
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
