PLAN #124-813

Key Specs


2544
sq ft

6
Beds

3
Baths

2
Floors

2
Garages

This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Plan Description


Shingled gable facades, railed front porches lend nostalgic appeal to this duplex. Garages are at center, so family living areas are well-separated from each other. Each has three bedrooms and a bathroom upstairs, with no shared wall here Unit A/B Identical 1st floor: 657 sq ft 2nd floor: 615 sq ft Garage: 306 sq ft

Floor Plans


Floor Plan - Main Floor Plan
Floor Plan - Main Floor Plan
Floor Plan - Upper Floor Plan
Floor Plan - Upper Floor Plan

Full Specs & Features


Dimension Depth : 49'
Height : 25'
Width : 52'
Area Garage : 612 sq/ft
Main Floor : 1314 sq/ft
Upper Floor : 1230 sq/ft
Ceiling Main Ceiling : 8'
Roof Roof Framing : Truss
Roof Load : 30
Primary Pitch : 7:12
Exterior Wall Framing Exterior Wall Finish : Siding/Shingle
Framing : 2"x6"
Bedroom Features Upstairs Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features Breakfast Nook
Peninsula Eating Bar
Additional Room Features Great Room Living Room
Main Floor Laundry
Garage Features Front Entry Garage
Outdoor Spaces Covered Front Porch
Covered Rear Porch
Code Compliance Irc 2006
Structural Information Provided Foundation Drawing
Structural 1st Floor Framing
Structural 2nd Floor Framing
Structural Roof Framing

What's Included In This Plan Set


Associated Designs, Inc.

Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
  • Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
  • Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
  • Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
  • Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
  • Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details. Foundation types vary; please call to confirm the foundation type of the plan you are interested in.
  • Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
  • Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc. Specific details such as fireplaces, stairways, decks, etc. Details are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
  • Section: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation.
  • Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
