PLAN #132-201

Key Specs


2545
sq ft

2
Beds

2
Baths

1
Floors

3
Garages

This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Floor Plans


Floor Plan - Main Floor Plan
Craftsman Floor Plan - Main Floor Plan Plan #132-201

Full Specs & Features


Dimension Depth : 65'
Height : 19' 11"
Width : 80'
Area Garage : 704 sq/ft
Main Floor : 2545 sq/ft
Ceiling Main Ceiling : 9'
Roof Roof Framing : Trusses
Roof Load : 25
Primary Pitch : 6:12
Roof Type : Comp
Exterior Wall Framing Framing : 2"x6"
Bedroom Features Upstairs Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features Eating Bar
Kitchen Island
Breakfast Nook
Additional Room Features Great Room Living Room
Main Floor Laundry
Storage Area
Lot Characteristics Suited For Narrow Lot
Outdoor Spaces Covered Front Porch
More Economical To Build
Code Compliance Irc 2006
Structural Information Provided Foundation Drawing
Structural 1st Floor Framing
Structural Roof Framing
Bedroom 2 166 sq/ft width 11' x depth 15' 2"
Den 177 sq/ft width 11' x depth 16' 2"
Dining Room 175 sq/ft width 13' x depth 13' 6"
Flex Room 230 sq/ft width 15' 2" x depth 15' 2"
Garage 693 sq/ft width 21' x depth 33'
Great Room 390 sq/ft width 19' 6" x depth 20'
Kitchen 243 sq/ft width 13' 6" x depth 18'
Master Bedroom 263 sq/ft width 15' 6" x depth 17'

What's Included In This Plan Set


Purchasing a CAD set or PDF set gives you a multi-build license. The 5 copy set allows you to build the home one time.

If you are building this plan in the state of Washington, please call us before placing your order.
  • Cover Sheet: The cover sheet includes the general notes and building code information, design standards and structural materials specifications required to construct your home.
  • Schedule Sheet: The schedule sheet includes the window, roof and foundation ventilation schedules, insulation and vapor barrier specifications, and exhaust fan ventilation schedule.
  • Detail Sheet: The detail sheet shows building components at large scale as required to explain construction of footings, foundation walls, concrete slabs, framed floors and walls, posts, beams, insulation, eaves, roofs, vents, stairs, skylights, and connections.
  • Foundation Plan Sheet: The foundation plan sheet shows the layout of the crawl space, walk-out basement or slab foundation. The foundation plan includes all necessary notes, dimensions, concrete walls, footing pads, posts, beams, bearing walls, crawlspace vents, footing schedule, steel reinforcing, and structural information. If you require a different foundation type, please contact us for modifications to your plan.
  • Floor Plan Sheet: Floor plans are horizontal cuts through each floor level of the home, usually at 5' above the floor. The floor plan shows the location of interior and exterior walls, doors, windows, stairs, closets, cabinets, flooring, appliances, plumbing fixtures, fireplaces, posts and beams. Floor plans also indicate vaulted, coffered, or box beam ceilings, cased openings and areas with ceiling soffits.
  • Roof Framing Plan Sheet: The roof framing plan shows the geometry of the hips, ridges, valleys, dormers, roof pitches, wall and plate heights, and overhangs. The plan also shows all individual roof framing members, trusses, rafters, beams, skylights, roof vents, gutters, downspouts, skylights, bearing walls under framing members, and point loads.
  • Elevation Sheet: Exterior elevations show all four sides of the house, describing the roofing, siding, and trim materials, doors, windows, roof pitches, skylights, gutters, chimneys, wall heights, finish grade and overall building height.
  • Building Section Sheet: Building sections are vertical cuts through the house from the roof to the foundation. The sections illustrate the construction sequence from bottom to top starting with excavation, proceeding up through the foundation, drainage, wall and floor framing, stair framing, roof framing, windows, doors, venting, and exterior and interior finishes. Wall plate heights for each floor are also delineated.
