Key Specs
2631
sq ft
4
Beds
2.5
Baths
1
Floors
2
Garages
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 17-2794
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 52'
Height : 28'
Width : 72'
Area
First Floor: 2631 sq/ft height 9'
Garage: 510 sq/ft
Porch: 341 sq/ft
Roof
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchenette Wet Bar
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Great Room Living Room
Main Floor Laundry
Media Room
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
More
Jack & Jill Bath
Rooms
Bedroom 2:
113 sq/ft width 10' 10" x depth 10' 6"
Bedroom 3:
128 sq/ft width 11' x depth 11' 8"
Bedroom 4:
132 sq/ft width 11' 4" x depth 11' 8"
Breakfast Room:
193 sq/ft width 16' 10" x depth 11' 6"
Dining Room:
196 sq/ft width 14' x depth 14'
Garage:
441 sq/ft width 21' x depth 21'
Great Room:
315 sq/ft width 17' 6" x depth 18'
Hall Bathroom:
64 sq/ft width 5' x depth 12' 10"
Kitchen:
196 sq/ft width 16' 10" x depth 11' 8"
Laundry Room:
79 sq/ft width 6' 6" x depth 12' 2"
Master Bathroom:
249 sq/ft width 11' 4" x depth 22'
Master Bedroom:
300 sq/ft width 15' x depth 20'
Media Room:
196 sq/ft width 14' x depth 14'
Porch - Rear:
374 sq/ft width 34' x depth 11'
Storage:
37 sq/ft width 14' 2" x depth 2' 8"
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost. (Walk out is not shown on elevations unless finished walk out.)
- CAD Unlimited Build comes with a free PDF.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. ** (cut throughs where applicable)
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
Plan Set
$1100.00
$1200.00
$1450.00
$1800.00
$2200.00
$2200.00
Foundation
$0.00
$0.00
$299.00
$299.00
Framing
$0.00
$299.00
Additional Options
$299.00
$80.00
$100.00
$395.00
$39.00
$149.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
