Full Specs & Features
Depth : 57'
Height : 25'
Width : 79' 8"
Basement Unfinished: 1692 sq/ft
First Floor: 2641 sq/ft height 9'
Garage: 916 sq/ft
Main Ceiling : 9'
Primary Pitch : 10:12
Roof Framing : Conventional
Roof Type : Shingle
Secondary Pitch : 6:12
Exterior Wall Framing
Exterior Wall Finish : Stone/Stucco
Framing : 2x4
Main Floor Master Bedroom
Walk In Closet
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Hobby Rec Room Game Room
Master Sitting Area
Unfinished Future Space
Side Entry Garage
Suited For Corner Lot
Covered Front Porch
Covered Rear Porch
Jack & Jill Bath
121 sq/ft width 11' x depth 11'
130 sq/ft width 10' x depth 13'
205 sq/ft width 13' 8" x depth 15'
Den/Office or Bedroom 1:
156 sq/ft width 12' x depth 13'
183 sq/ft width 12' 3" x depth 15'
320 sq/ft width 16' x depth 20'
119 sq/ft width 7' 5" x depth 16' 2"
189 sq/ft width 14' x depth 13' 6"
40 sq/ft width 4' x depth 10'
270 sq/ft width 18' x depth 15'
77 sq/ft width 11' x depth 7'
What's Included In This Plan Set
- Cover Page: Front elevation and informative reference sections including: general notes and design criteria
- Elevations: Drafted at 1/4" scale for the front and 1/8" scale for the rear and sides. All elevations are noted and an aerial view of the roof is provided, showing all hips, valleys and ridges.
- Foundation: Drafted at 1/4" scale. Poured or block basement or slab foundations are standard. Shows the HVAC equipment, structural information, steel beam and pole locations and the direction and spacing of the floor system above. Alternate foundations are available for a fee.
- Main Level Floor Plan: 1/4" scale. Fully dimensioned from stud to stud for ease of framing. The detailed drawings include such things as structural header locations, framing layout and kitchen layout.
- Second Level Floor Plan: 1/4" scale. Dimensioned from stud to stud and drafted to the same degree of detail as the main level floor plan.
- Elevations: Useful for the cabinet and bidding process, this page shows all kitchen and bathroom cabinets as well as any other cabinet elevations.
- Electrical and Sections: Illustrated on a separate page for clarity, the electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall and stair sections are provided to further explain construction of these areas.
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
