Key Specs
2646
sq ft
4
Beds
3.5
Baths
2
Floors
3
Garages
with Code CTB2023 (limit 1)
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 20-2122
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Floor Plans
Full Specs & Features
Dimension
Depth : 43'
Height : 31'
Width : 72'
Area
First Floor: 1311 sq/ft height 9'
Garage: 956 sq/ft height 9'
Porch: 142 sq/ft
Second Floor: 1335 sq/ft height 8'
Ceiling
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 8:12
Roof Framing : stick
Roof Load : 30
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : 2"x4"
Bedroom Features
Upstairs Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Family Room Keeping Room
Play Flex Room
Storage Area
Upstairs Laundry
Outdoor Spaces
Covered Front Porch
Rooms
Bedroom 2:
143 sq/ft width 11' x depth 13'
Bedroom 3:
110 sq/ft width 10' x depth 11'
Bedroom 4:
110 sq/ft width 10' x depth 11'
Dining Room:
130 sq/ft width 10' x depth 13'
Eating:
187 sq/ft width 11' x depth 17'
Family Room:
210 sq/ft width 14' x depth 15'
Flex Room:
182 sq/ft width 14' x depth 13'
Garage:
811 sq/ft width 33' 4" x depth 24' 4"
Garage Storage:
143 sq/ft width 11' x depth 13'
Kitchen:
130 sq/ft width 10' x depth 13'
Master Bedroom:
210 sq/ft width 14' x depth 15'
What's Included In This Plan Set
- Cover Page: Front elevation and informative reference sections including: general notes and design criteria
- Elevations: Drafted at 1/4" scale for the front and 1/8" scale for the rear and sides. All elevations are noted and an aerial view of the roof is provided, showing all hips, valleys and ridges.
- Foundation: Drafted at 1/4" scale. Poured or block basement or slab foundations are standard. Shows the HVAC equipment, structural information, steel beam and pole locations and the direction and spacing of the floor system above. Alternate foundations are available for a fee.
- Main Level Floor Plan: 1/4" scale. Fully dimensioned from stud to stud for ease of framing. The detailed drawings include such things as structural header locations, framing layout and kitchen layout.
- Second Level Floor Plan: 1/4" scale. Dimensioned from stud to stud and drafted to the same degree of detail as the main level floor plan.
- Elevations: Useful for the cabinet and bidding process, this page shows all kitchen and bathroom cabinets as well as any other cabinet elevations.
- Electrical and Sections: Illustrated on a separate page for clarity, the electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall and stair sections are provided to further explain construction of these areas.
Plan Set
$981.75
$1406.75
$1632.00
$2057.00
$607.75
Foundation
$0.00
$208.25
$208.25
$208.25
Framing
$0.00
$208.25
Additional Options
$208.25
$212.50
$85.00
$33.15
$148.75
$425.00
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
