Full Specs & Features
Depth : 63'
Height : 28'
Width : 43'
First Floor: 2689 sq/ft height 10'
Garage: 481 sq/ft height 10'
Porch: 128 sq/ft
Primary Pitch : 10:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Formal Dining Room
Main Floor Master Bedroom
Walk In Closet
Additional Room Features
148 sq/ft width 13' x depth 11' 5"
154 sq/ft width 14' x depth 11'
143 sq/ft width 13' x depth 11'
192 sq/ft width 16' x depth 12'
154 sq/ft width 11' 5" x depth 13' 6"
420 sq/ft width 20' x depth 21'
144 sq/ft width 12' x depth 12'
272 sq/ft width 16' x depth 17'
230 sq/ft width 14' 5" x depth 16'
Master Walk-In Closet:
120 sq/ft width 10' x depth 12'
56 sq/ft width 7' x depth 8'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
