PLAN 17-2633
Key Specs
2789
sq ft
4
Beds
3
Baths
2
Floors
2
Garages
Cost to Build Reports Only $9.99 with Code CTB2022 (Limit 1)
This report will provide you cost estimates based on location and building materials.
Get Personalized Help
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
PLAN 17-2633
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.Plan Description
Full Specs & Features
Height : 29'
Width : 72' 4"
First Floor: 1977 sq/ft height 9'
Second Floor: 812 sq/ft
Roof Framing : Conventional
Framing : Wood - 2x4
Formal Dining Room
Formal Living Room / Parlor
Split Bedrooms
Great Room Living Room
Unfinished Future Space
3rd BR Closet:
22 sq/ft width 2' 6" x depth 9'
Bedroom 2:
164 sq/ft width 12' 4" x depth 13' 4"
Bedroom 2 Closet:
20 sq/ft width 2' 6" x depth 8'
Bedroom 3:
164 sq/ft width 12' 4" x depth 13' 4"
Bedroom 3 Closet:
20 sq/ft width 2' 6" x depth 8'
Bedroom 5:
139 sq/ft width 12' 4" x depth 11' 4"
Bonus Room - Finished:
286 sq/ft width 14' 4" x depth 20'
Breakfast Room:
139 sq/ft width 12' 4" x depth 11' 4"
Dining Room:
152 sq/ft width 12' 4" x depth 12' 4"
Foyer:
129 sq/ft width 7' 10" x depth 16' 6"
Garage:
416 sq/ft width 20' x depth 20' 10"
Gathering Room:
126 sq/ft width 9' 6" x depth 13' 4"
Hall:
width 3' 6" x depth 0"
Hall Bathroom:
40 sq/ft width 5' x depth 8'
Kitchen:
187 sq/ft width 12' 6" x depth 15'
Master Bathroom:
162 sq/ft width 18' x depth 9'
Master Bedroom:
270 sq/ft width 17' 10" x depth 15' 2"
Master Closet:
30 sq/ft width 5' x depth 6'
Porch - Front:
270 sq/ft width 33' 10" x depth 8'
Storage:
36 sq/ft width 4' x depth 9'
Utility Room:
54 sq/ft width 6' x depth 9'
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost. (walk out is not shown on elevations unless finished walk out)
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. ** (cut throughs where applicable)
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
