Key Specs


2905
sq ft

3
Beds

3
Baths

2
Floors

2
Garages

This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.

Plan Description


A 3-story marvel best describes this house plan. Open, airy, and spacious only begins to outline what this special plan has to offer. From boat storage and work space in the garage to balconies and covered lanias above, this home is perfect for the waterfront. With an elevator to tie it all together, this plan has it all! Check it out today! (Not available for construction in Key Largo or Islamorada in the Florida Keys.)

Floor Plans


Floor Plan - Main Floor Plan
Mediterranean Floor Plan - Main Floor Plan Plan #1017-134
Floor Plan - Upper Floor Plan
Mediterranean Floor Plan - Upper Floor Plan Plan #1017-134
Floor Plan - Lower Floor Plan
Mediterranean Floor Plan - Lower Floor Plan Plan #1017-134

Full Specs & Features


Dimension Depth : 45'
Height : 35'
Width : 52'
Area Garage : 1238 sq/ft
Lower Floor : 292 sq/ft
Main Floor : 1502 sq/ft
Upper Floor : 1111 sq/ft
Bedroom Features Upstairs Master Bedrooms
Walk In Closet
Kitchen Features Kitchen Island
Additional Room Features Great Room Living Room
Outdoor Spaces Courtyard
Loft Balcony
More Wheelchair Adaptable
Bedroom 2 179 sq/ft width 13' x depth 13' 10"
Bedroom 3 185 sq/ft width 14' 8" x depth 12' 8"
Dining Room 166 sq/ft width 13' x depth 12' 10"
Entry width 0" x depth 0"
Foyer width 0" x depth 0"
Garage 550 sq/ft width 13' x depth 42' 4"
Garage Two 556 sq/ft width 14' 4" x depth 38' 10"
Great Room 387 sq/ft width 17' 4" x depth 22' 4"
Kitchen 241 sq/ft width 14' 4" x depth 16' 10"
Lanai 209 sq/ft width 22' x depth 9' 6"
Lanai 274 sq/ft width 14' 4" x depth 19' 2"
Lanai 143 sq/ft width 14' 4" x depth 10'
Laundry width 0" x depth 0"
Loft width 0" x depth 0"
Master Bath width 0" x depth 0"
Master Suite 274 sq/ft width 14' 4" x depth 19' 2"
Storage 352 sq/ft width 22' x depth 16'
