PLAN 45-165
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 80'
Height : 31'
Width : 66'
Area
First Floor: 2092 sq/ft height 9'
Second Floor: 1027 sq/ft height 8'
Ceiling
Ceiling Details : Ceiling Heights are 9'-8" and up.
Main Ceiling : 9'
Roof
Primary Pitch : 9:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Stucco
Framing : 2"x6"
Bedroom Features
Main Floor Master Bedroom
Upstairs Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Main Floor Laundry
Storage Area
Sunroom
Garage Features
Oversized Garage
Rear Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Covered Front Porch
Grill Deck Sundeck
Screened Porch
More
Jack & Jill Bath
Energy Efficient Features
Energy Efficient Design
Rooms
Bedroom 2:
168 sq/ft width 14' x depth 12'
Bedroom 3:
168 sq/ft width 14' x depth 12'
Bedroom 4:
192 sq/ft width 16' x depth 12'
Dining Room:
210 sq/ft width 14' x depth 15'
Eating:
108 sq/ft width 12' x depth 9'
Family Room:
375 sq/ft width 25' x depth 15'
Garage:
660 sq/ft width 22' x depth 30'
Kitchen:
102 sq/ft width 12' x depth 8' 6"
Master Bedroom:
305 sq/ft width 16' 6" x depth 18' 6"
Study:
210 sq/ft width 14' x depth 15'
What's Included In This Plan Set
- Information Cover Sheet
- Foundation Plan: Each plan is designed on a specific type of foundation. Optional foundation types may be offered. Refer to the general information listed with each plan to determine foundation type and options available.
- Detailed Floor Plans: Complete with the window and door schedules. Electrical plans, with suggested switch, fixture and outlet locations, may be part of the floor plan or a separate drawing.
- Exterior Views
- Building Sections & Interior Elevations
- Complete Construction Details
- Complete Specifications: Specifications list the types of materials used in the construction of the home. Finish schedules are provided.
Plan Set
$1250.00
$1350.00
$1460.00
$1475.00
$2300.00
Foundation
$0.00
$175.00
$175.00
Additional Options
$150.00
$50.00
$100.00
$39.00
$200.00
$75.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
