PLAN 124-735
Key Specs
3143
sq ft
5
Beds
3.5
Baths
2
Floors
3
Garages
Cost to Build Reports Only $9.99 with Code CTB2021 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Get Cost-To-Build Report
Or order by phone: 1-800-447-0027
Questions?
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-800-447-0027
Phone: 1-800-447-0027
Hours: Mon-Fri, 9AM - 8:30PM (EST)
See our Terms & Conditions and Privacy Policy.
PLAN 124-735
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.Plan Description
? Families that love to entertain will find much to appreciate in this
elegant European-style home ? The family room is completely open to the
dining room and a generously sized kitchen ? Owners? suite luxuries
include a two-section closet, walk-in shower and two-sided fireplace
Full Specs & Features
Dimension
Depth : 49'
Height : 34' 8"
Width : 98'
Height : 34' 8"
Width : 98'
Area
Bonus: 616 sq/ft height 9'
First Floor: 2150 sq/ft height 9'
Garage: 1200 sq/ft height 9'
Second Floor: 993 sq/ft height 9'
First Floor: 2150 sq/ft height 9'
Garage: 1200 sq/ft height 9'
Second Floor: 993 sq/ft height 9'
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 10:12
Roof Framing : 2x6
Roof Load : 25
Roof Type : Truss
Roof Framing : 2x6
Roof Load : 25
Roof Type : Truss
Exterior Wall Framing
Exterior Wall Finish : siding/stone
Framing : 2"x6"
Framing : 2"x6"
Bedroom Features
Guest Suite
Main Floor Master Bedroom
Split Bedrooms
Upstairs Bedrooms
Walk In Closet
Main Floor Master Bedroom
Split Bedrooms
Upstairs Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Family Room Keeping Room
Loft
Main Floor Laundry
Play Flex Room
Loft
Main Floor Laundry
Play Flex Room
Garage Features
Oversized Garage
Side Entry Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Suited For View Lot
Outdoor Spaces
Balcony
Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck
Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck
Code Compliance
Irc 2006
Structural Information Provided
Foundation Drawing
Structural 1st Floor Framing
Structural 2nd Floor Framing
Structural Roof Framing
Structural 1st Floor Framing
Structural 2nd Floor Framing
Structural Roof Framing
Rooms
Balcony:
155 sq/ft width 15' 6" x depth 10'
Bedroom 2:
139 sq/ft width 12' 8" x depth 11'
Bedroom 3:
139 sq/ft width 11' x depth 12' 8"
Bedroom 4:
117 sq/ft width 10' 8" x depth 11'
Bonus Room - Unfinished:
456 sq/ft width 31' 6" x depth 14' 6"
Dining Room:
276 sq/ft width 12' 8" x depth 21' 10"
Garage:
1050 sq/ft width 30' x depth 35'
Guest Suite:
143 sq/ft width 13' x depth 11'
Loft:
210 sq/ft width 12' 6" x depth 16' 10"
Master Bedroom:
