Key Specs
3183
sq ft
4
Beds
3
Baths
2
Floors
2
Garages
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
Use Code CTBSUMMER
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 137-321
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 46'
Height : 36'
Width : 61'
Area
Bonus: 553 sq/ft
First Floor: 1785 sq/ft height 9'
Second Floor: 1398 sq/ft
Roof
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Kitchen Features
Breakfast Nook
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Hobby Rec Room Game Room
Loft
Main Floor Laundry
Open Floor Plan
Storage Area
Unfinished Future Space
Garage Features
Side Entry Garage
Outdoor Spaces
Balcony
Covered Front Porch
More
Wheelchair Adaptable
Rooms
Bedroom 2:
168 sq/ft width 12' x depth 14'
Bedroom 3:
168 sq/ft width 14' x depth 12'
Bonus Room - Finished:
436 sq/ft width 16' 8" x depth 26' 2"
Breakfast Room:
115 sq/ft width 10' x depth 11' 6"
Dining Room:
200 sq/ft width 14' x depth 14' 4"
Family Room:
300 sq/ft width 20' x depth 15'
Foyer:
145 sq/ft width 11' 4" x depth 12' 10"
Garage:
484 sq/ft width 22' x depth 22'
Kitchen:
247 sq/ft width 14' x depth 17' 8"
Living Room:
256 sq/ft width 14' x depth 18' 4"
Master Bedroom:
231 sq/ft width 14' x depth 16' 6"
Study:
132 sq/ft width 12' x depth 11'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
Plans are typically drawn to ¼” scale and include:
- Foundation Plan(s): This page shows all necessary notations and dimensions including footings, support columns, walls, and excavated/unexcavated areas.
- Floor Plan(s): Detailed plans for each level showing room dimensions, wall partitions, windows and doors, fixture locations, and ceiling treatments.
- Exterior Elevations: Views of the home from all four sides showing exterior materials, roof slope, ridge heights, siding and trim notes.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements.
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
- Building Section(s): Shows the relationship between different levels, wall heights, and the overall building volume. May include details like foundation, framing, insulation, and finishes.
- Electrical Plan(s): Shows the location of lights, receptacles, switches, etc. Some plans that do not include an electrical plan may have it available for an additional fee.
- Construction Notes / Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
- Rendering(s): Designer’s rendering of front elevation
Plan Set
$782.00
$858.50
$1020.00
$1020.00
$680.00
Foundation
$0.00
Framing
$0.00
Additional Options
$46.75
$140.25
$335.75
$33.15
$140.25
$42.50
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
