Key Specs
3190
sq ft
3
Beds
3.5
Baths
2
Floors
3
Garages
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
Use Code CTBBF (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 54-286
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 82' 8"
Height : 36' 2"
Width : 63' 3"
Area
Bonus: 529 sq/ft
First Floor: 2332 sq/ft
Garage: 701 sq/ft
Second Floor: 858 sq/ft
Roof
Primary Pitch : 0:0
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Additional Room Features
Loft
Main Floor Laundry
Master Sitting Area
Unfinished Future Space
Outdoor Spaces
Balcony
Rooms
Bedroom 2:
139 sq/ft width 12' 5" x depth 11' 3"
Bedroom 3:
145 sq/ft width 11' 2" x depth 13'
Bonus Room - Finished:
316 sq/ft width 17' 5" x depth 18' 2"
Dining Room:
199 sq/ft width 13' 9" x depth 14' 6"
Garage:
682 sq/ft width 20' 5" x depth 33' 5"
Grand Room:
350 sq/ft width 17' 7" x depth 19' 11"
Keeping Room:
245 sq/ft width 17' 5" x depth 14' 1"
Kitchen:
206 sq/ft width 13' 5" x depth 15' 5"
Living Room:
162 sq/ft width 11' 5" x depth 14' 3"
Master Bedroom:
224 sq/ft width 16' 9" x depth 13' 5"
Master Sitting Area:
62 sq/ft width 11' 5" x depth 5' 6"
What's Included In This Plan Set
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1436.00
$2276.00
$2352.00
Foundation
$0.00
$280.00
$280.00
Framing
$0.00
$280.00
Additional Options
$200.00
$132.00
$316.00
$31.20
$132.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
