Key Specs
3219
sq ft
4
Beds
3.5
Baths
2
Floors
3
Garages
Phone: 1-800-447-0027
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 328-463
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-447-0027 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 42' 6"
Width : 82' 8"
Area
First Floor: 1883 sq/ft height 9'
Second Floor: 1336 sq/ft height 9'
Roof
Roof Framing : Conventional
Roof Type : Asphalt
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Loft
Main Floor Laundry
Vaulted / Cathedral Ceilings
Outdoor Spaces
Balcony
Covered Front Porch
More
Jack & Jill Bath
Rooms
Bedroom 2:
156 sq/ft width 13' x depth 12'
Bedroom 3:
147 sq/ft width 12' 10" x depth 11' 6"
Bedroom 4:
183 sq/ft width 10' 8" x depth 17' 2"
Den:
175 sq/ft width 13' 6" x depth 13'
Dinette:
147 sq/ft width 10' 6" x depth 14'
Dining Room:
188 sq/ft width 13' x depth 14' 6"
Family Room:
352 sq/ft width 16' x depth 22'
Garage:
768 sq/ft width 24' x depth 32'
Kitchen:
182 sq/ft width 13' x depth 14'
Living Room:
189 sq/ft width 14' x depth 13' 6"
Master Bedroom:
247 sq/ft width 14' x depth 17' 8"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$725.00
$850.00
$1000.00
$2100.00
$650.00
Foundation
$0.00
Framing
$0.00
Additional Options
$60.00
$100.00
$39.00
$200.00
$40.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
